Samsung NP-R528CE User Manual (FreeDos) Service Manual

- This Document can not be used without Samsung's authorization -
Part List : NP-R528-DA03HU
Ver. Location Part Number Part Name & Specification Q'ty SA/SNA Parent Part
0001 A0010 3903-000444 CBF-POWER CORD;DT,EU/KR,CP3,IEC320 C5,25 1 SA BA99-16006A
0001 A1001 BA46-12340A S/W CD;UTILITY,Bremen-L/UL,-,1.0,FREEDOS 1 SA BA99-16006A
0001 B0001 BA75-02374A UNIT-HOUSING_BOTTOM;BREMEN-15L,SEC,PC/AB 1 SA NP-R528-DA03HU
0001 B0003 BA81-08518A DOOR-MEMORY;BREMEN-15L,PC/ABS,W104.9*L11 1 SA BA97-02997A
0001 B0009 BA81-06960A RUBBER-FOOT;MIAMI,HS50,L19*W6.5*H3.9mm,S 4 SA BA75-02374A
0001 B0010 BA81-04694A RUBBER-FOOT_REAR;TIANJIN,DOMESTIC,BLACK, 2 SA BA75-02374A
0001 B0100 BA75-02377A UNIT-DOOR_HDD;BREMEN-15L,SEC,PC/ABS,W122 1 SA BA97-02997A
0001 B0302 BA81-02795A LINK-BATTERY_L;QINGDAO,POM,L26.4*W10.8*H 1 SA BA75-02374A
0001 B0303 BA81-07310A LINK-BATTERY_R;QINGDAO,DOMESTIC,POM,L26. 1 SA BA75-02374A
0001 B0402 BA81-06380A KNOB-BATTERY_L;QINGDAO-D,PC+ABS,T1.2,W34 1 SA BA75-02374A
0001 B0403 BA81-06381A KNOB-BATTERY_R;QINGDAO-D,PC+ABS,T1.2,W34 1 SA BA75-02374A
0001 B0501 BA61-00780A SPRING ETC-BATT;AQUILA-P,STS304,CD0.3,ID 2 SA BA75-02374A
0001 B0701 BA61-01212A DUMMY CARD-SD_3IN1;BREMEN-15L,PC/ABS,T2. 1 SA BA97-02997A
0001 D0005 BA92-05997A ASSY BOARD-ODD_SUB;BREMEN-M,ODD I/F BOAR 1 SA NP-R528-DA03HU
0001 D1002 BA59-02459A DVD-SUPERMULTI;TS-L633B,8x,150ms,SATA,2M 1 SC BA96-04448A
0001 D1002 BA59-02571A DVD-SUPERMULTI;DV-W28S-V90,8X,140ms,SATA 1 SA BA96-04447A
0001 D1002 BA59-02671A DVD-SUPERMULTI;TS-L633C,8x,190ms,SATA,2M 1 SA BA96-04533B
0001 D1002 BA59-02730A DVD-SUPERMULTI;DS-8A4S,8X,160ms,SATA,2MB 1 SA BA96-04623A
0001 D1006 BA41-01049A FFC-ODD;BONN,1.0,Film,12P,T0.3mm,L40*W6. 1 SA BA92-06338C
0001 D1006 BA41-01095A FFC-ODD;BONN,1.0,Film,12P,T0.3,L40*W6.5M 1 SA BA92-06338C
0001 D2000 BA81-04551A BRACKET-ODD;XIAN,DOMESTIC,SECC,L27*W10.6 1 SA BA97-02998D
0001 D3000 BA75-02378A UNIT-BEZEL_DVDSUPERMULTI;BREMEN-15L,PC/A 1 SA BA97-02998A
0001 D3000 BA75-02378D UNIT-BEZEL_DVDSUPERMULTI;BREMEN-15L,PC/A 1 SA BA97-02998D
0001 G0003 BA59-02572A MODULE-WLAN;AR5B95,WLL6160-D99(ROHS),-,1 1 SA BA92-06338A
0001 G0003 BA59-02573A MODULE-WLAN;AR5B95,T77H121.05,-,1x1,Half 1 SA BA92-06338A
0001 I0001 0902-002508 IC-MICROPROCESSOR;AW80577GG0491MA,2.2GHz 1 SA NP-R528-DA03HU
0001 I0002 1105-001921 IC-DRAM MODULE;M471B5673DZ1-CF8,DDR3 SDR 1 SA NP-R528-DA03HU
0001 I0002 1105-001923 IC-DRAM MODULE;M471B2874DZ1-CF8,DDR3 SDR 1 SA NP-R528-DA03HU
0001 I0002 1105-002055 IC-DRAM MODULE;M471B5673EH1-CF8,DDR3 SDR 1 SA NP-R528-DA03HU
0001 I0002 1105-002056 IC-DRAM MODULE;M471B2873EH1-CF8,DDR3 SDR 1 SA NP-R528-DA03HU
0001 I0002 1105-002114 IC-DRAM MODULE;M471B5673FH0-CF8,DDR3 USO 1 SA NP-R528-DA03HU
0001 I0002 1105-002116 IC-DRAM MODULE;M471B2873FHS-CF8,DDR3 SOD 1 SA NP-R528-DA03HU
0001 I0003 BA59-02468A LCD PANEL-15.6HD;N156B6-L06,15.6 Inch HD 1 SA BA96-04509A
0001 I0003 BA59-02505A LCD PANEL-156HD;LTN156AT02-C,15.6 HD,LED 1 SA BA96-04509A
0001 I0003 BA59-02659A LCD PANEL-156HD;BT156GW01,1366*768,DE,0. 1 SA BA96-04509A
0001 I0003 BA59-02738A LCD PANEL-156HD;N156B6-L10,15.6HD,LED,22 1 SA BA96-04509A
0001 I0005 BA59-02341A HDD;320G,HTS543232L9A300,S63,H16,D16385, 1 SC NP-R528-DA03HU
0001 I0005 BA59-02347A HDD;320G,MHZ2320BH-G2,S63,H16,D16385,9.5 1 SC NP-R528-DA03HU
0001 I0005 BA59-02355A HDD;320G,HM320JI,S63,H16,D16385,9.5mm,2. 1 SC NP-R528-DA03HU
0001 I0005 BA59-02377A HDD;320G,MK3252GSX,S63,H16,D16385,H9.5mm 1 SC NP-R528-DA03HU
0001 I0005 BA59-02395A HDD;320G,WDC-WD3200BEVT-22ZCT0,S63,H16,C 1 SC NP-R528-DA03HU
0001 I0005 BA59-02455A HDD;320G,MHZ2320BH-FFS-G2,S63,H16,D16385 1 SA NP-R528-DA03HU
0001 I0005 BA59-02576A HDD;320GB,ST9320325AS,S63,H16,C16383,9.5 1 SA NP-R528-DA03HU
0001 I0005 BA59-02598A HDD;320G,HTS545032B9A300,S63,H16,D16385, 1 SA NP-R528-DA03HU
0001 I0005 BA59-02624A HDD;320G,HM320II,S63,H16,D16385,H9.5mm,2 1 SA NP-R528-DA03HU
0001 I0005 BA59-02675A HDD;320GB,MK3263GSX,S63,H16,C16383,9.5mm 1 SA NP-R528-DA03HU
0001 I0005 BA59-02759A HDD;320G,HM321HI,S63,H16,D16385,H9.5mm,2 1 SA NP-R528-DA03HU
0001 I0006 BA59-02833Q KEYBOARD;BREMEN-2L,101,Membrane,-,HU,-,B 1 SA NP-R528-DA03HU
0001 I0007 BA44-00242A ADAPTOR;0335A1960,AD-6019R,19VDC,3.16A,- 1 SA BA99-16006A

Samsung NP-R528CE User Manual (FreeDos) Specifications

General

Model	NP-R528CE
Operating System	FreeDOS
Category	Laptop
Hard Drive	320 GB
Screen Size	15.6 inches
Weight	2.5 kg
Color	Black
Screen Resolution	1366 x 768
Battery	6-cell
