Chapter 1
Getting Started
Overview
Left View
21 4 53 6 7 8
1 DC Jack
A jack to connect the AC adapter that
supplies power to the computer.
2
Wired LAN Port
Connect the Ethernet cable to this port.
3 Fan Vents
The internal heat of the computer is
emitted through these holes.
If the vents are blocked the
computer may overheat.
Avoid blocking the vents as this may
be dangerous.
4 Monitor Port
A port used to connect a monitor, TV
or projector supporting a 15pin D-SUB
interface.
5
Digital Video/
Audio Port (HDMI)
(Optional)
You can connect an HDMI cable to this
port. Using this port, you can enjoy
digital video and audio on the TV.
6
USB Port
(Optional)
You can connect USB devices to the USB
port such as a keyboard/mouse, digital
camera, etc.
7
Microphone Jack
A jack used to connect the microphone.
8
Headphone Jack
A jack used to connect the headphones.

Samsung NP300E5C Series 3 15.6" Notebook Specifications

General

Display Size	15.6 inches
Display Resolution	1366 x 768
Optical Drive	DVD Super Multi
Wireless	802.11 b/g/n
LAN	10/100/1000 Gigabit Ethernet
Bluetooth	Bluetooth 4.0
Processor	Intel Core i5-3210M
RAM	4 GB
Storage	500GB HDD
Graphics	Intel HD Graphics 4000
Operating System	Windows 8
Ports	1 x USB 3.0, 2 x USB 2.0, HDMI, VGA, RJ-45, Headphone output, Microphone input
Card Reader	SD, SDHC, SDXC
Battery	6-cell
Weight	2.3 kg
Dimensions	367.9 x 242.9 x 29 ~ 34.9 mm (14.48 x 9.56 x 1.14 ~ 1.37 inch)
