■ 5-2 OUTDOOR MAIN PCB
76
5
4
3
2
1
8 9 10 11
OLP /COND THERMISTOR CONNECTOR SMAW250A-04 WHT
OUT/DISCHARGE THERMISTOR CONNECTOR SMAW250A-04 RE
BLDC-FAN CONNETCOR YAN396-06V WHT
EEV-A CONNECTOR SMAW250A-05 RED
DISPLAY CONNECTOR SMW200-10 NTR
DISPLAY CONNECTOR SMAW250A-03 RED
PC DOWNLOADCONNECTOR SMW200-10 BLK
S NE T CONNECTOR SMW200-04 NTR
AS-PRO DOWNLOAD CONNECTOR SMAW200A-07 WHT
DISPLAY CONNE CTORS MW200-05 NTR
DOWNLOAD-INV CONNECTOR S MW200-10 RED
1
2
3
4
5
9
11
10
8
7
6
