42
If you use face detection options, your
camera can detect a human face. When
focusing on a human face, the brightness
of the face is also adjusted. You can also
capture natural facial expressions by using
self portrait, smile shot or blink detection.
Normal
This mode detects the face position of the subject automatically
and then sets the focus and exposure. Select this mode for quick
and easy face picture.
Ä
Selectable modes: Program, DUAL IS, Beauty Shot, Portrait,
Children, Beach & Snow
1. The size and position of the auto
focus frame is set at the face of the
subject automatically.
2. Press the shutter button halfway.
The focus frame turns to green
when the focus is activated.
3. Press the shutter button fully to take
a picture.
Face Detection
This function can detect up to 10 persons.
When the camera recognizes many people at the same
time, it will focus on the nearest person.
The Digital zoom is not activated in this mode.
When the camera detects a target face, the white color
focus frame will be displayed over the target face and the
grey color focus frame appears over the remaining faces.
Press the shutter button halfway down to focus on the face
and the white focus frame turns green.
In some conditions this function cannot work properly.
- When a person wears dark glasses or some part of the
face is hidden.
- When the person being taken does not look at the camera.
- Camera doesn't detect a face as the brightness is too dark
or too bright.
- The distance between the camera and object is far.
The maximum available Face Detection range is 2.5m (Wide).
The nearer the subject, the faster the camera can recognize
the subject.
In [Beauty Shot], [Portrait], and [Children] mode, the
[Face Detection] function setting is set to its default value.
Shooting ( )
Face Detection
Back Move

Table of Contents

Other manuals for Samsung PL80

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung PL80 and is the answer not in the manual?

Samsung PL80 Specifications

General IconGeneral
Megapixel12.4 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios16:9
Maximum image resolution4000 x 3000 pixels
Still image resolution(s)1024 x 768, 2048 x 1536, 2592 x 1944, 3264 x 2448, 3968 x 2232, 3984 x 2656
Digital zoom5 x
Focal length range5.1 - 25.5 mm
Digital SLRNo
Minimum RAM256 MB
Minimum processorPentium III, PowerG3
Power supply typeDC
Aperture range (F-F)3.4 - 5.9
Camera shutter speed1/8 - 1/2000 s
Effective sensor resolution12.2 pixels
Minimum storage drive space250 MB
Minimum system requirementsUSB CD-ROM
Compatible operating systemsWindows 2000/XP Mac 10.3
Focal length (35mm film equivalent)28 - 140 mm
FocusTTL
Focus adjustmentAuto
Normal focusing range0.8 m
Macro focusing range (tele)0.5 - 0.8 m
Macro focusing range (wide)0.05 - 0.8 m
Normal focusing range (wide)0.8 - ∞ m
Light meteringcentre-weighted, spot
Flash modesauto, Red-eye reduction, Slow synchronization
Flash range (tele)0.5 - 2 m
Flash range (wide)0.4 - 3.4 m
Flash recharging time4 s
Motion JPEG frame rate30 fps
Video formats supportedAVI
Maximum video resolution640 x 480 pixels
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
USB version2.0
Product colorSilver
Scene modesBacklight, beach, Close-up (macro), Fireworks, Night portrait, Portrait, Sunset, Landscape (scenery)
Image editingresizing, rotating
Photo effectsSkin tones, Vivid
White balanceauto, Cloudy, custom modes, daylight, Fluorescent, Incandescent
Camera playbackmovie, single image, slide show, thumbnails
Battery typeBP-70A
Battery capacity740 mAh
Power requirements4.2 V
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 85 %
Compatible memory cardssd, sdhc
Weight and Dimensions IconWeight and Dimensions
Depth20.2 mm
Width96.8 mm
Height57.5 mm
Weight110 g
