Samsung PPM63M7FS - Connector Pin Connections and Roles

Wiring Diagram
Samsung Electronics 6-3
6-1-1 Pin Connection
1
CN809(SMPS)
↔
CN4000(X Board)
Pin Description
1 Vs
2 Vs
3 GND
4 GND
5
Vg
2
CN810(SMPS)
↔
CN5004(Y Board)
Pin No. Signal
1 Vs
2 Vs
3 NC
4 GND
5 GND
6 GND
7 Vg
3
CN807(SMPS)
↔
CN2001(Logic Board)
Pin No. Signal
1 GND
2 Vs_ON
3 GND
4 PS_ON
5 GND
6 5.3V
7 GND
8 5.3V
9 5.3V
10 5.3V
4
CN808(SMPS)
↔
CN2508(E-BUFFER)
Pin No. Signal
1 5.3V
2 GND
3 Va
6
CN801(SMPS) ↔ CN101(MAIN Board)
Pin No. Signal Pin No. Signal Pin No. Signal
1 NC(AUTO_V) 9 GND_5.3V 17 GND_12V
2 PS_ON 10 GND_5.3V 18 GND_12V
3 GND_STBY 11 GND_5.3V 19 GND_12V
4 STBY 12 GND_5.3V 20 12V
5 GND_18V AMP 13 5.3V 21 12V
6 GND_18V AMP 14 5.3V 22 12V
7 18V AMP 15 5.3V 23 NC(FAN_DET)
8 18V AMP 16 5.3V 24 NC(FAN_ON)
5
CN811(SMPS)
↔
CN2708(G-BUFFER)
Pin No. Signal
1 5.3V
2 GND
3 Va
7
CN1401(MAIN Board)
↔
FUNCTION
Pin No. Signal
1 KEY_INPUT1
2 KEY_INPUT2
3 AGND
