Wiring Diagram
Samsung Electronics 6-5
6-1-2 Connector role
Loc. No. Description
CN5400
Scan Driver IC of Y-Main transmits scan signal to Y ports of module.
CN5401
CN5402
CN5500
CN5501
CN5502
CN5410
Connect Y-Main Scan(High) with Y-Main Scan(Low) by signal.
CN5510
CN5003
Connect Y-Drive with Y Main Scan. Supply drive signal to Y ports of panel in order.
CN5005
CN5006
CN5012
CN2008
Supply Y-drive signal to Y-Drive from logic board,
CN5002
CN810
Supply Vg, Vs power to Y-Drive from SMPS.
CN5004
CN809
Supply Vg, Vs power to X-Drive from SMPS.
CN4000
CN801
Supply 5V, 18V, 12V power to Main board from SMPS and connect STBY, PS_ON signal.
CN1101
CN800 Connect AC-inlet to SMPS and supply 100~240V power to SMPS.
CN2000
Supply X-drive signal to X-Drive from logic board,
CN4001
CN4014
X-Drive transmits scan signal to X ports of module.
CN4015
CN4016
CN4017
CN807
Supply 5.3V power to logic board from SMPS and connect VS_on, PS_On, STBY signals.
CN2001
CN2010
Connect Main board with Logic board and transmit LVDS visual signal to Logic board.
CN2203_FHD
CN2006
Transmit data signal and control signal of Logic board to E-Buffer.
CN2502
CN2005
Transmit data signal and control signal of Logic board to F-Buffer.
CN2600
CN2007
Transmit data signal and control signal of Logic board to G-Buffer.
CN2700
CN2500
Connect E-Buffer with F-Buffer by signal.
CN2602
CN2601
Connect F-Buffer with G-Buffer by signal.
CN2701
CN811
Supply 5.3V, Va power to F-Buffer from SMPS.
CN2708
CN1401 Connect Key_Input1, Key_Input2, LED, IR signals of function assy to Main board and supply 5V power.
