Samsung QB55R User Manual

Table of contents
Preparations
Checking the Components 3
Parts 4
Q*32R*/Q*43R*/Q*49R*/Q*50R*/Q*55R*/
Q*65R*/Q*75R*/Q*82R*/Q*85R
* 4
QB98R
5
Anti-theft Lock 6
Ports 7
Q*43R*/Q*49R*/Q*50R*/Q*55R*/Q*65R*/
Q*75R*/Q*82R*/Q*85R
* 7
QM43R-A/QM50R-A/QM55R-A/QM65R-A/
QM75R-A/QM43R-B/QM50R-B/QM55R-B/
QM65R-B/QM75R-B
8
QM32R
9
QM32R-A/QM32R-AN/QM32R-B
10
QB98R
11
QM32R-T
12
QM43R-T/QM55R-T
13
Control menu 14
Administrator menu (Supported models:
QMR-T
) 15
Precautions when handling the panel 16
2
Specifications
General 24
Preset Timing Modes 27
Appendix
Licence 28
Before Installing the Product (Installation
Guide) 17
Tilting Angle and Rotation 17
Ventilation 17
Installing the Wall Mount 18
Preparing before installing Wall-Mount 18
Installing the Wall Mount 18
Wall Mount Kit Specifications (VESA) 19
Using a touchscreen monitor
(Supported models: QMR-T)
Touchscreen monitor 20
Read below before using the product 20
Connecting the touch overlay 20
Connecting the touchscreen monitor 21
Connecting to a PC 21
Connecting to a laptop or tablet PC 21
Configuring the touchscreen monitor
settings 22
Calibration 22

Samsung QB55R Specifications

General

Color gamut	92 %
Pixel pitch	0.105 x 0.315 mm
Response time	8 ms
Display diagonal	55 \
Display brightness	350 cd/m²
Display technology	LED
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
LED backlighting type	Edge-LED BLU
Contrast ratio (typical)	4700:1
Display number of colors	16.78 million colors
Active display area (W x H)	1209.6 x 680.4 mm
Dynamic contrast ratio marketing name	Mega Contrast
AC input voltage	100 - 240 V
Heat dissipation	487.6 BTU/h
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	108 W
Package depth	163 mm
Package width	1402 mm
Package height	858 mm
Package weight	23600 g
L2 cache	2048 KB
User memory	4.12 GB
Plug and Play	Yes
Memory clock speed	1500 MHz
VGA (D-Sub) input ports	0
Ethernet LAN (RJ-45) ports	1
Purpose	Universal
Operating hours (hours/days)	16/7
Internal memory	2.5 GB
Processor cores	4
Processor family	ARM Cortex
Processor frequency	1.7 GHz
Audio formats supported	AC3
Image formats supported	JPEG, PNG
Video formats supported	AVC, AVS, H.263, H.264, HEVC, MPEG1, MPEG2, MPEG4, VC-1, VP8, VP9
Internal storage capacity	8 GB
Operating system installed	Tizen 4.0
Certification	60950-1, EMC B
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	9.2 mm
Placement supported	Indoor
Bezel width (bottom)	11.2 mm
Panel mounting interface	200 x 200 mm
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	ENERGY STAR
RMS rated power	20 W
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth	46.3 mm
Width	1235.1 mm
Height	707.9 mm
Weight	18100 g
