Samsung QM32R User Manual

23
3
Select the product from Display under Display options. Next, select Calibrate.
4
Perform calibration following the onscreen instructions displayed as shown in the image.
To provide calibration samples, tap the crosshair each
time that it appears on the screen.
Right-click anywhere on the screen to return to the
last calibration point. Press the Esc button to close
the tool. Do not change your screen orientation until
you have completed the calibration process.
5
After calibration is complete, the message Do you want to save the calibration data?
appears. Select Yes.
Digitizer Calibration Tool
Yes No
Do you want to save the calibration data?
6
The touchscreen monitor has been calibrated successfully.
"
Selecting Reset will remove the calibration data.

Samsung QM32R Specifications

General

Pixel pitch	0.36 x 0.36 mm
Response time	8 ms
Display diagonal	32 \
Display brightness	400 cd/m²
Display technology	-
Vertical scan range	48 - 75 Hz
Horizontal scan range	30 - 81 kHz
LED backlighting type	Edge-LED
Contrast ratio (typical)	5000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	80 cm
Dynamic contrast ratio marketing name	Mega Contrast
DVI port	No
USB port	Yes
USB ports quantity	2
HDMI ports quantity	3
VGA (D-Sub) input ports	0
Package depth	120 mm
Package width	812 mm
Package height	512 mm
Package weight	8000 g
Product color	Black
Product design	Digital signage flat panel
Placement supported	Indoor
Bezel width (bottom)	8.8 mm
Panel mounting interface	200 x 200 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Purpose	Universal
Operating system installed	Tizen 4.0
AC input voltage	100 - 240 V
AC input frequency	50 / 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	44 W
Annual energy consumption	64 kWh

Weight and Dimensions

Depth	34.6 mm
Width	725.1 mm
Height	419.6 mm
Weight	5700 g
