Samsung RB2155SH - 10-8) Option Circuit

32
Circuit Descriptions
1) Freezer Temperature Shift (Unit ˚F)
SHIFT
Reference
-1.0
-2.0
-4.0
-6.0
+2.0
+4.0
+6.0
D601
-
-
-
-
•
•
•
•
D602
-
-
•
•
-
-
•
•
D603
-
•
-
•
-
•
-
•
2) Refrigerator Temperature Shift (Unit ˚F)
SHIFT
Reference
-1.0
-2.0
-4.0
-6.0
+2.0
+4.0
+6.0
D604
-
-
-
-
•
•
•
•
D605
-
-
•
•
-
-
•
•
D606
-
•
-
•
-
•
-
•
Temperature and function values can be abjustable by using main PCB switching diode.
• Note : the values have been preset in factory. If is recommended not to change the value arbitrarily.
When the option function is modified, a power should be turned off and on, again.
