operating _29
02 OPERATING
20. Connect the wire and then insert it into the
Cover-Control.
Insert the wire into the Cover Hinge and then
the white taping part should be located as
below picture (1).
Fold the Fixer not to disassemble as below
picture (2).
(2)
Only on models with external display.
21. Assemble the Cover Hinge to match the Hinge.
* RB37* model only
22. Assemble the Cap Space Door (additional part)
on back side.
* RB37* model only
23. Insert the Cover Wire Door on the top of Fridge
door and then push it to assemble completely.
Check the wire position that should be located
the back side of Cover Wire Door.
* RB37* model only
