Remove the Cover Wire ( 1. 1 ) and Cap door L
( 2 ).
Remove the Cover Hinge to push a hook like 2.
below Pictures.
Disconnect the housing. 3.
And then remove 2 screws on the Upper Hinge
and Upper Hinge.
The door is heavy, be careful not to injure
yourself when removing the door.
CAUTION
Remove the fridge door from the Middle hinge 4.
by carefully lifting the door straight up.
The door is heavy, be careful not to injure
yourself when removing the door.
Disassemble the Middle hinge.5.
Remove the freezer door from the Bottom 6.
hinge by carefully lifting the door straight up.
The door is heavy, be careful not to injure
yourself when removing the door.
CAUTION
CAUTION
( 2 )
( 1 )
To Next Page
