Samsung RD080PHXEA - Selecting and Installing Y-Joints; Keeping Refrigerant Pipes Clean and Dry

E-19
ENGLISH
Installing the Refrigerant Pipe Work
(Continued)
Selecting the Y-joint
 Select the first Y-joint depending on the outdoor unit capacity.
Select the other Y-joints depending on the total capacity of attached indoor units below the
selected joint individually.
Selecting the first Y-joint
Outdoor capacity (kW) Y-joint model
RD060PHXEA
MXJ-YA1509K
RD070PHXEA
RD080PHXEA
RD110PHXEA
RD140PHXEA
RD160PHXEA
The other Y-joint
Total capacity of attached
indoor units below this
Y-joint (kW)
Y-joint model
X < 20.2 MXJ-YA1509K
Keeping Refrigerant Pipe Clean and Dry
 To prevent foreign materials or water from entering the pipe, Pipes shall be sealed by caps.
