E-38
Setting the Option Switch and Function of the Keys
(Continued)
Dip Switch Setup
K13 K14K15 K16K9 K10 K11 K12K5 K6 K7 K8
  
Switch No.
Function (Cooling capacity compensation)
K7 K8
ON ON No Cooling Frequency compensation (Default)
ON OFF Frequency compensation 105% (frequency*compensation value)
OFF ON Frequency compensation 110% (frequency*compensation value)
OFF OFF Frequency compensation 115% (frequency*compensation value)
Switch No.
Function (Communication Tracking)
K5
ON Set indoor unit address manually
OFF Set indoor unit address automatically
Switch No.
Function (Night silence)
K9 K10
ON ON Not use Night silence (Default)
ON OFF Night silence Step_1 (Basic Fan RPM in EEPROM)
OFF ON Night silence Step_2 (10% speed reduction of Step_1)
OFF OFF Night silence Step_3 (20% speed reduction of Step_1)
Switch No.
Function (Heating capacity compensation)
K11 K12
ON ON No high pressure target (Default)
ON OFF High pressure target [standard 0.2MPa (2.03 kgf/cm²)]
OFF ON High pressure target [standard -0.1 MPa (1.01 kgf/cm²)]
OFF OFF High pressure target [standard +0.1 MPa (1.01 kgf/cm²)]
Switch No.
Function (All electric current Option)
6kW 7kW 8kW 11kW 14kW 16kW
K13 K14
ON ON All electric current (Default) 12.5A 14.8A 16.6A 24A 26A 28A
ON OFF All electric current I_Down_OP1 10.5A 12.5A 14A 23A 24A 26A
OFF ON All electric current I_Down_OP2 9A 11A 12A 20A 22A 24A
OFF OFF All electric current I_Down_OP3 9A 10A 10A 20A 20A 20A
 Standard:3.0MPa
