REMOVING THE REFRIGERATOR DOORS
• To reattach the Refrigerator doors, assemble parts in reverse order.
Be careful not to missplace the parts of refrigerator.
DISASSEMBLE THE FREEZER DRAWER
1. Push the upper drawer until it reaches to the cabinet rear wall.
2. Remove the tilting pocket(
1
) by pulling on both brackets(
2
)
upward at the same time.
1
2
3. Take out the lower basket (
3
) by lifting the basket up from rail
system.
4. Remove four 10mm hex-head bolts from both sides.
5. Lift the freezer door up from the rails.
3
Setting up your French Door
Refrigerator
10_ Setting Up
