REMOVING THE REFRIGERATOR DOORS
1) With the door closed, remove the upper hinge cover (➀) using a screwdriver, and then disconnect
the wires (➁).
2) Remove hinge screws (➂) and ground screw (➃) counter-clockwise, and take off the upper hinge (➄) along the
arrow (➅). Take care when removing the door to ensure that it does not fall on you.
Removing the Freezer Door
• Lift the door straight up.
• Be careful not to pinch the water tubing and wire harness on the door.
• Place doors on a protected surface.
NOTE
3) Remove the door from the lower hinge (⑦) by
carefully lifting the door (
➇ ).
4) Remove the lower hinge (➈) using a screwdriver.
DA99-00494B (EN)-1.3 9/3/07 10:32 AM Page 22

Samsung RS23FESW Specifications

General

Type	Side-by-Side
Total Capacity	23 cu. ft.
Refrigerator Capacity	14.5 cu. ft.
Freezer Capacity	8.5 cu. ft.
Ice Maker	Yes
Water Dispenser	Yes
Color	White
Cooling System	Twin Cooling Plus
Energy Star Certified	Yes
Defrost Type	Frost-Free
