Maintenance
English36
Maintenance
Step-by-step instructions
STEP 1 Remove the doors
1. Use a Phillips screwdriver to loosen the
screws (x3) in three holes on the top
table. Then, gently pull out the top table.
2. Decouple the wire connectors.
3. Loosen the bolts on the top hinge.
4. Gently lift up the freezer door to
remove it.
