22
DISASSEMBLY & REASSEMBLY
PART NAME DESCRIPTION FIGURE
Disassembly of
Dispenser
pull them both sides and upward.
1. Pick Assy Cover-Dispenser like the picture,
3-5. Disassembling the Refrigerator Door
Control Panel
shown,and unlock the tabs.
2.Insert a at-head screwdriver on the slot as
1. Remove inlay lm as shown, take from the
corner out without damage the inlay.
3. Disconnect the wire connector.
CAUTION
Be careful not to scratch.
Disassembly of
water valve
1. Disconnect the wire connector.
2. Disassembly Hose.
CAUTION
When disassembling, make sure the
unit turned o.
Door
Handle
tols eht no revird wercs daeh-talf a tresnI .1
by twisting the handle and disassemble the
cover-handle.
2. Remove 4 screws.
CAUTION
When disassembling, make sure the
unit turned o If you want to assembly,
follow the reverse order.
