Connecting and Using a Source Device
2
2 Connecting and Using a Source Device
S19E410HY / S22E410HY / S24E410HL
Do not connect the power cable before connecting all other cables. Ensure you connect a source
device first before connecting the power cable.
1 Connect the HDMI cable to the [HDMI IN] port on the back of the product and the HDMI port on the
PC.
2 Connect the DC power adapter to the product and a power socket. Next, turn on the power switch
on the PC. (For details, refer to "2.2.4 Connecting the Power".)
3 When the input source is not connected, use the [ ] button to change the input source to
HDMI.
2.2.3 Connection Using the HDMI-DVI Cable
S19E310HY / S22E310HY / S22E310H / S24E310HL / S27E310H
Do not connect the power cable before connecting all other cables. Ensure you connect a source
device first before connecting the power cable.
1 Connect the HDMI-DVI cable to the [HDMI IN] port on the back of the product and the DVI port on
the PC.
2 Connect the DC power adapter to the product and a power socket. Next, turn on the power switch
on the PC. (For details, refer to "2.2.4 Connecting the Power".)
3 When the input source is not connected, use the [ ] button to change the input source to
HDMI.
