- 12 -
Preparations
Installation
Attaching the Stand
" Before assembling the product, place the product down on a flat and stable surface so that the screen is facing
downwards.
" Disassembly is the reverse order of assembly.
S24AM50*
x 2
1
1 2
Put the stand base onto the stand
neck as the direction shown in the
figure. Check that the stand neck is
firmly connected.
Tightly fasten the connecting screw
at the bottom of the stand base.
3
3
4
4
Place a soft cloth over the table to protect the product and place
the product onto the cloth so that the front of the product is facing
downwards. Push the assembled stand into the main body in the direction
of the arrow as shown in the figure. Tightly fasten the connecting screw at
the bottom of the main body.
Stand assembly is complete.
