15. Parts List
LOCATION NO. CODE NO. DESCRIPTION SPECIFICATION Q'TY REMARK
P001 DC99-00164A ASSY-PAINT FRAME S803J/BLUE,COLD/SLIM-MO 1 S803JGB2/YLW
P001 DC99-00138A ASSY-PAINT FRAME S803J,COLD/SLIM-MODEL 1 S803JGW(P)2/YLW
P001 DC99-00167A ASSY-PAINT FRAME S803J/SILVER,COLD/SLIM-MODEL 1 S803JGS2/YLW
P001 DC99-00166A ASSY-PAINT FRAME S803J/GOLD,COLD/SLIM-MODEL 1 S803JGE2/YLW
P001 DC61-40345A BRACKET-PRESSURE GI or GA,SWK-P12,T1.0,- 1
P003 DC97-00702D ASSY-FRAME FRONT SB-PJT/WHT,ROUND-TYPE 1 S803JGB2/YLW
P003 DC97-00702A ASSY-FRAME FRONT P6091,ROUND-TYPE 1 S803JGW(P)2/YLW
P003 DC97-00416C ASSY-FRAME FRONT SWF-P12,FRAME-FRONT(EUN BI) 1 S803JGS2/YLW
P003 DC97-00702B ASSY-FRAME FRONT S803J/EUN BI,ROUND-TYPE 1 S803JGS2/YLW
P003 DC97-00702E ASSY-FRAME FRONT S803J/GOLD,ROUND-TYPE 1 S803JGE2/YLW
P003 DC97-00417A ASSY-FRAME PLATE(U) SWF-P12,FRAME-PLATE( 1
R003 DC91-12077A ASSY-CLAMP DIAPHGRAM SWF-P12,TUB 1
R005 DC97-02099D ASSY-DRUM S1005J/KRNJM,LEFTER TYPE 1
R006 DC47-00006B HEATER KAWAI,P-SLIM MODEL,SUS316L,-,-,23 1
R007 DC97-02137A ASSY-TUB BACK S1005J,SLIM-MODEL/TUB 1
R008 6602-001073 BELT-TIMING GEAR POLYURETHAN,1270,J3,MEG 1
R010 DC61-00856A BRACKET-HEATER SB-PJT,STS430,-,-,-,-,- 1
R011 DC61-60499B CLIP-TUB HSWR,P1291,-,NO/PAINT, 7
R012 DC66-60149A DAMPER-SHOCK SWF-P12,-,-,80N, 2
R013 DC61-20219C DOOR-DIAPHRAGM P805J,EPDM,-,GRY,-,-,(WAS 1
R014 DC62-10303A HOSE-AIR -,EPDM,ID24,-,-,L130,BLK,SWF-P1 1
R015 DC62-10305A HOSE-DRAWER TUB -,EPDM,ID35,-,-,L158,BLK 1
R016 DC62-00121A HOSE-FILTER TUB S1005J,EPDM,ID65,-,-,-,- 1
R017 DC62-10311A HOSE-PRESSURE -,EPDM,ID13.5,-,-,-,BLK,SW 1
R018 DC31-00002H MOTOR-DRUM HXGP2I,S803J,-,50HZ,-,-,LOW-R 1
R019 DC60-50148B NUT-HEX SM20C(NYLON),M12,-,-,ZPC3(YEL), 1
R020 DC66-10176B PULLEY ALDC,-,D297,P1291,ID12.5 1
R021 DC62-00007A SEAL-OIL -,NBR(SD25),BLK,-,-,-,P6091/NBU 1
R022 DC61-60496A SPACER-HEATER SWF-P12,PBT(GP2301),-,-,-, 2
R023 DC61-00365B TUB-FRONT SL-600,FRPP(GR15%)SAMBAK,-,-,- 1
R024 DC62-20311A VANE-CHECK SWF-P12,EPDM,-,-,BLK,-, 1
R025 DC66-00137A WEIGHT-BALANCER SL-600,CONCREET,SLIM/UPP 1
R025 DC66-00172A WEIGHT-BALANCER SL-600,GC-150,SLIM/LOWER 1
R026 DC61-40345A BRACKET PRESSURE GI or GA,SWK-P12,T1.0,- 1
T024 DC96-00053B ASSY-WIRE HARNESS P8091/6091(SUB),LOW-RP 1
T031 DC61-00041A CUSHION-MOTOR SWF-6V,BUTYL,-,-,-,ID16/OD 1
T031 DC61-00041A CUSHION-MOTOR SWF-6V,BUTYL,-,-,-,ID16/OD 1
V001 DC61-00055C COVER-DOOR S803J,ABS,-,-,-,-,BLUE,DANBY 1 S803JGB2/YLW
V001 DC61-00055A COVER-DOOR P6091,ABS,-,-,-,-,-,WHT,ROUND 1 S803JGW2/YLW
V001 DC61-00055D COVER-DOOR S803J,ABS,-,-,-,-,PEAR/WHT,DANBY 1 S803JGP2/YLW
V001 DC61-00055F COVER-DOOR S803J,ABS,-,-,-,-,SILVER,DANBY 1 S803JGS2/YLW
V001 DC61-00055E COVER-DOOR S803J,ABS,-,-,-,-,GOLD,DANBY 1 S803JGE2/YLW
V002 DC97-00100C ASSY-HINGE S1005J,OPEN ANGLE 180DEG 1
V003 DC61-00057A HOLDER-GLASS DWM599W,ABS(HG-0760),-,-,-, 1
V007 DC91-12078A ASSY-WIRE DIAPHRAGM SWF-P12,FRAME-FRONT 1
V009 DC61-00013A DOOR-GLASS GLASS,NTR,SWF-P12 1
V010 DC61-00122A DOOR-LOCK S/W 250V(120V)16A,BLK,DANBY.P6 1
V017 DC66-00016A LEVER-DOOR POM,-,-,-,-,NTR,DWM599W,DANBY 1 S803JGB(W,P,S)2/YLW
V017 DC66-00016A LEVER-DOOR POM,-,-,-,-,NTR,DWM599W,DANBY 1 S803JGE2/YLW
Y001 MF-S803J-02 ASSY PCB PARTS 2WAY 1
