15. Parts List
LOCATION NO. CODE NO. DESCRIPTION SPECIFICATION Q'TY REMARK
B006 DC97-02079A ASSY-LEG S1005J,SLIM/25MM 4 S803JGB(P,S,E)2/YLW
B006 DC97-02079A ASSY-LEG S1005J,SLIM/25MM 4 S803JGW2/YLW
C007 DC96-00524B ASSY-M.WIRE HARNESS P6093,COLD/2WAY/MANU 1
C008 DC97-03032H ASSY-PANEL CONTROL S803J/MASKING,BLUE-2(RUSSIA) 1 S803JGB2/YLW
C008 DC97-01785M ASSY-PANEL CONTROL S803J,RUSSIAN 1 S803JGW2/YLW
C008 DC97-02492R ASSY-PANEL CONTROL S803J/MASKING,PEARL/WHT 1 S803JGP2/YLW
C008 DC97-02492V ASSY-PANEL CONTROL S803J/MASKING,SILVER(RUSSIA) 1 S803JGS2/YLW
C008 DC97-02492T ASSY-PANEL CONTROL S803J/MASKING,GOLD(RUSSIA) 1 S803JGE2/YLW
C009 DC62-00024F VALVE-WATER B1215J,NYLON66/250TRMN,-,-,N 1
C010 DC61-10316B CAP-RINSE SEW-740DR,PP(TB-52),-,-,-,WHT, 1
C021 DC64-00357A INLAY-PANEL S803J,PC(T=0.5),-,-,-,BLUE-2 1 S803JGB2/YLW
C021 DC64-00186B INLAY-PANEL S803J,PC(T=0.5),-,-,-,TRP,RUSSIAN 1 S803JGW2/YLW
C021 DC64-00186S INLAY-PANEL S803JGP,PC(T=0.5),-,-,-,PEARL/WHT 1 S803JGP2/YLW
C021 DC64-00186T INLAY-PANEL S803JGS,PC(T=0.5),-,-,-,SILVER,RUSSIA 1 S803JGS2/YLW
C021 DC64-00186R INLAY-PANEL S803JGE,PC(T=0.5),-,-,-,GOLD(EUN BI) 1 S803JGE2/YLW
C023 DC32-30006P SENSOR PRESSURE DN-S14(P1291),TERMINAL-T 1
G002 DC97-02106A ASSY-FIXER TUB S1005J,SLIM-PJT 3
G003 DC97-00139D ASSY-HOSE DRAIN(O) S1005J,PP(BB110)/L182 1
G008 DC96-00146A ASSY-POWER CORD P1291~P6091,250V/16A(PV) 1
G009 DC90-11110K ASSY-PUMP DRAIN SWF-P12,220V~240V/50Hz 1
G012 DC64-00085A BUTTON-ENCODER PV2-PJT,TRP/ABS,-,-,GRN,- 1
G015 DC61-10673A CAP-DRAIN SWF-P12,PP(TB53),-,-,-,WHT,-, 1
G018 DC61-00440A SHUTTER SLIM-PJT,PP,WHT, 1 S803JGB(P,S,E)2/YLW
G018 DC61-00440A SHUTTER SLIM-PJT,PP,WHT, 1 S803JGW2/YLW
G020 DC61-10672C COVER-FRONT(L) S803JGB,-,-,-,-,-,BLUE,CI 1 S803JGB2/YLW
G020 DC61-10672A COVER-FRONT(L) SWF-P12,PP(BJ-730),-,-,-,-,WHT 1 S803JGW(P)2/YLW
G020 DC61-10672E COVER-FRONT(L) S803JGS,-,-,-,-,-,SILVER,CIS 1 S803JGS2/YLW
G020 DC61-10672D COVER-FRONT(L) S803JGE,-,-,-,-,-,GOLD(EUN BI),CIS 1 S803JGE2/YLW
G023 DC62-10302A HOSE-DRAIN SWF-P12,EPDM,ID5.5,-,-,L220,B 1
G024 DC62-10022K HOSE-PUMP S1005J,PP(BB110),ID21,OD26,-,L 1
G025 DC62-10289B HOSE-WATER(C) WIP4013SRW,PVC+NYLON,ID10. 1
G027 DC64-00082C KNOB-ENCODER P2-PJT,ABS,-,-,-,-,SILVER,- 1 S803JGB(P,S,E)2/YLW
G027 DC64-00082A KNOB-ENCODER PV2-PJT,TRP/ABS,-,-,-,-,WHITE 1 S803JGW2/YLW
G028 DC63-00119X PANEL-DRAWER S803J,ABS(HG00760),-,-,-,-, 1 S803JGB2/YLW
G028 DC63-00119G PANEL-DRAWER -,ABS(HG-0760),-,-,-,-,WHT,S803JGW 1 S803JGW2/YLW
G028 DC63-00119L PANEL-DRAWER S803JGP/YLP,ABS(HG-0760),-,-,-,- 1 S803JGP2/YLW
G028 DC63-00119M PANEL-DRAWER S803JGS/YLP,ABS(HG-0760),-,-,-,- 1 S803JGS2/YLW
G028 DC63-00119K PANEL-DRAWER S803JGE/YLP,ABS(HG-0760),-,-,-,-, 1 S803JGE2/YLW
J001 DC97-00851P ASSY-COVER TOP S803JGB,MDF/CIS-BLUE/SLIM 1 S803JGB2/YLW
J001 DC97-00851H ASSY-COVER TOP S1005J,MDF/WHT/SLIM 1 S803JGW2/YLW
J001 DC97-00851L ASSY-COVER TOP S803JGP,MDF(PEARL/WHT)SLIM 1 S803JGP2/YLW
J001 DC97-00851M ASSY-COVER TOP S803JGS,MDF/SILVER/SLIM 1 S803JGS2/YLW
J001 DC97-00851K ASSY-COVER TOP S803JGE,MDF/GOLD(EUN BI)SLIM 1 S803JGE2/YLW
J006 DC61-00366A BODY-DRAWER SL-600,TB-53,-,-,-,-,-,- 1
J008 DC29-00006A FILTER-EMI DFC-2712R,P/PV/SLIM,250V,12A, 1
J010 DC67-00051A HOSE-DRAWER S1093~S6093,EPDM,-,-,-,-,BLK 2
J011 DC61-60180A SLEEVE-PLUG NYLON#6,SEW-720DR,-,-,NTR 2
J012 DC61-00441A SPRING-HANGER S1005J,HSWR,CD3.0,-,L175,L 2
J014 DC97-02132C ASSY-HOUSING DRAWER S1093~S6093/2-WAY,SL 1
