12. Setting up a wash machine.
12-1 Remove the safety device for carriage
1) Remove 5 safety device volts with a enclosed wrench for safety device remove
2) Plug the 5 holes with 5 caps after removing the 5 safety device volts.
* Take care of 5 safety device volts and a wrench , you need these when you move wash machine safely.
Caution
You must remove safety device before use , if not, you have much vibration or much load can by impacted on
the machine.
12-2 Install the wash machine on the leveled place.
With the water level adjustment device, adjust the 4 adjustment legs to install the machine leveled on the right,
left, front and rear side. machine's install condition and size is following.
12-2-1 Initial assembled condition (ass'y cover top)
1) Adjustment legs are stick to the bottom of the machine,
when the machine comes out of factory. this condition is
ideal for vibration and noise.
2) When you install the machine initially or move the machine in use,
unscrew the 4 legs to the left and place the machine level and spin
the locking nuts and tighten it strongly.
1. Remove safety device behind of machine
●
To protect the machine, remove the
assembled 5 safety device
2. Plug the 5 holes
●
Plug the 5 holes after safety device
withthecapsenclosedinsideof
washing tub
