User s Manual
Specifications
General
Model Name SAMTRON 76DF
Picture Tube
Type 17" (43cm) DynaFlat (40.6cm viewable)
Deflection angle 90°
Dot Pitch 0.20mm (Horizontal)
Screen type Silica coated with anti-electronic properties (TCO : Multilayer coating)
Medium-short persistence phosphor.
Maximum Resolution
1280 Dots, 1024 Lines
Active Display
Horizontal 12.3 ± 0.16 inch (312 ± 4 mm)
Vertical 9.2 ± 0.16 inch (234 ± 4 mm)
Synchronization
Horizontal 30 ~ 70 kHz
Vertical 50 ~ 160 Hz
Input Signal, Terminated
Analog 0.7 Vpp positive at 75 ohms
Separate Sync TTL level, positive or negative
Display Color
Unlimited
Maximum Pixel Clock
110 MHz
Power Supply
AC 100 ~ 240V ± 10%, 60Hz/50 Hz ± 3Hz
Power Consumption
90W (Maximum),
75W (Nominal)
Dimensions (WxDxH)
398 x 412 x 400 mm (with base)
Weight
16.2 kg
Plug and Play Capability
This monitor can be installed on any Plug & Play compatible system. Interaction of the monitor and
computer systems will provide the best operating conditions and monitor settings. In most cases,
monitor installation will proceed automatically, unless the user wishes to select alternate settings.
General Specifications
