14. Reference Information
14-1 Deck Operating Description
Fig. 14-1 Top View
Œ DRUM BASE RAIL ASS’Y
´ MOTOR LOADING ASS’Y
ˇ GEAR WHEEL
¨ GEAR TENSION
ˆ POLE BASE S ASS’Y
Ø ARM TENSION ASS’Y
∏ REEL DISK S ASS’Y
” BRAKE SOFT S ASS’Y
’ COVER REEL BRAKE ASS’Y
˝ HOLDER FPC
Ô DRUM ASS’Y
 MOTOR CAPSTAN ASS’Y
Ò GEAR CAPSTAN
Ú POLE BASE T ASS’Y
Æ ARM REVIEW ASS’Y
ı ARM PINCH ASS’Y
˜ REEL DISK T ASS’Y
¯ BRAKE T ASS’Y
˘ SWITCH MIC
Œ
´
ˇ
¨
ˆ
Ø
∏
”
’
˝
Ô

Ò
Ú
Æ
ı
˜
¯
˘
14-1-1 Nomenclature
