Samsung SC-D362 - 6 Electrical Parts List

This Document can not be used without Samsung’s authorization
Loc.No Part No Description ; Specification Q’ty S.N.A Remark Loc.No Part No Description ; Specification Q’ty S.N.A Remark
Samsung Electronics
6-1
P001 AD92-00026A ASSY PCB-MAIN BOARD;SC-D364/XAA,DRA 1 SA
B701 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
B702 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
C111 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C112 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C113 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C114 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C115 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216 1 SA
C116 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C117 2203-005922 C-CER,CHIP;4700NF,20%,6.3V,X5R,TP,2 1 SA
C118 2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,1005 1 SA
C119 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C120 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 SA
C121 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C122 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 SA
C123 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C201 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C202 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C203 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,1005 1 SA
C204 2203-005922 C-CER,CHIP;4700NF,20%,6.3V,X5R,TP,2 1 SA
C207 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C208 2404-001246 C-TA,CHIP;10uF,20%,6.3V,WT,TP,2012 1 SA
C209 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C210 2404-001246 C-TA,CHIP;10uF,20%,6.3V,WT,TP,2012 1 SA
C211 2203-005627 C-CER,CHIP;470nF,10%,10V,X5R,1608 1 SA
C212 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C213 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C214 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C215 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C216 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C217 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C218 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C219 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C220 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C221 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 SA
C222 2203-006006 C-CER,CHIP;0.005NF,?0.25PF,50V,C0G, 1 SA
C223 2203-006006 C-CER,CHIP;0.005NF,?0.25PF,50V,C0G, 1 SA
C224 2203-006006 C-CER,CHIP;0.005NF,?0.25PF,50V,C0G, 1 SA
C225 2203-006006 C-CER,CHIP;0.005NF,?0.25PF,50V,C0G, 1 SA
C227 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C229 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C230 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C232 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C241 2404-001247 C-TA,CHIP;22UF,20%,4V,WT,TP,2012 1 SA
C242 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C243 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C244 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C245 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C246 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C247 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C248 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C301 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C302 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C303 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C304 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C305 2203-005922 C-CER,CHIP;4700NF,20%,6.3V,X5R,TP,2 1 SA
C306 2203-005922 C-CER,CHIP;4700NF,20%,6.3V,X5R,TP,2 1 SA
C307 2203-005686 C-CER,CHIP;2200nF,20%,10V,X5R,TP,20 1 SA
C308 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C309 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C310 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C311 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C316 2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,1005 1 SA
C317 2203-005993 C-CER,CHIP;68NF,10%,16V,X7R,TP,1005 1 SA
C319 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C320 2203-005686 C-CER,CHIP;2200nF,20%,10V,X5R,TP,20 1 SA
C321 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C322 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,1005 1 SA
C323 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,1005 1 SA
C324 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C326 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C327 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C328 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C329 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C330 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C331 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C333 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C334 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C335 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C336 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C337 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C340 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 SA
C341 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,1005 1 SA
C401 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C402 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C403 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C406 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C407 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C409 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C411 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216 1 SA
C412 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C413 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C414 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C416 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C417 2203-000254 C-CER,CHIP;10nF,10%,16V,X7R,1005 1 SA
C418 2203-002487 C-CER,CHIP;4.7nF,10%,25V,X7R,1005 1 SA
C419 2203-005481 C-CER,CHIP;47nF,10%,10V,X7R,TP,1005 1 SA
C420 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C421 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C422 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C423 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C424 2203-000234 C-CER,CHIP;0.1NF,5%,50V,C0G,TP,1005 1 SA
C425 2203-006047 C-CER,CHIP;33NF,10%,16V,X7R,TP,1005 1 SA
C426 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C427 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C428 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C429 2203-005923 C-CER,CHIP;1000NF,20%,6.3V,X5R,TP,1 1 SA
C430 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 SA
C431 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,1005 1 SA
C432 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C501 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C502 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C503 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,1005 1 SA
C504 2404-001251 C-TA,CHIP;22UF,20%,7V,-,TP,3216 1 SA
6. Electrical Parts List
