Exploded View and Parts List
5-5Samsung Electronics
Loc. No Parts No. Description ; Specification Q’ty S.N.A Remark
C849 AD61-02358A BRACKET-GROUND LEFT;DRAGON2-PJ,STS, 1 SA
FL610 3809-001773 FFC CABLE-FLAT;30V,80,40mm,60P,0.5m 1 SA
P003 AD92-00019A ASSY PCB-LEFT BOARD;SC-D363,DRAGON2 1 SA
P004A AD97-10590A ASSY PCB-FUNCTION BOARD;DRAGON2-PJ, 1 SA
P054 AD97-04289A ASSY-SPEAKER;-,D5-PJ,G-17S08-0823 1 SA
P091 AD97-10691E ASSY-CASE LEFT;ASSY,DRAGON2-PJ,SD/M 1 SA
P247 AD97-10796A ASSY-COVER TOP;-,DRAGON2-PJ,UV(X) 1 SA
W126 6003-001300 SCREW-TAPTITE;CH,+,B,M1.7,L4,ZPC(BL 5 SA
W226 6003-001148 SCREW-TAPTITE;PH,+,B,M1.7,L6,ZPC(BL 2 SA
To Next Page
