Samsung SCB-3020 User Manual

33
How to use OSD Menu
ALARM OUT
If you set a desired menu item to ON, the camera
will sound an alert if it detect the appropriate
motion.
ALARM OUT
MOTION ON
FIXED/MOVED ON
FENCE
LINE ON
AREA
ENTER ON
EXIT ON
 
❖
PRIVACY ZONE SETUP
ePRIVACY ZONEf
1 2 3 4 5 6
7 8 9 10 11 12
PRIVACY SET ON
STYLE MOSAIC1
 
The PRIVACY function will protect your privacy by
screening the privacy area that you have specifi ed
during monitoring. You can specify up to 12 privacy
zones.
If you set the PRIVACY SET to ON, your PRIVACY
ZONE settings will be applied.
You can change the style to adjust the mosaic size and
color of the PRIVACY ZONE.
ePRIVACY ZONEf
1 2 3 4 5 6
7 8 9 10 11 12
PRIVACY SET ON
STYLE COLOR
Y-LEVEL [055]
RED [055]
BLUE [055]
 

Samsung SCB-3020 Specifications

General

Image Sensor	1/3" Super HAD CCD II
Iris Control	DC Auto Iris
Operating Temperature	-10°C to +50°C
Power Supply	12V DC / 24V AC
Power Consumption	3.5W
Signal to Noise Ratio	52dB
Resolution	600 TVL
Weight	370g
