Samsung SCL810 - Page 71

Samsung Electronics3-4
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CP40 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP46 2203-001660 C-CERAMIC,CHIP;0.004NF,0.25PF,16V,NP0,TP
CP47 2203-002605 C-CERAMIC,CHIP;0.008nF,0.25pF,50V,NP0,TP
CP48 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP49 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CP50 2203-000041 C-CERAMIC,CHIP;0.01NF,0.25PF,50V,C0G,TP,
CP51 2203-001660 C-CERAMIC,CHIP;0.004NF,0.25PF,16V,NP0,TP
CV01 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV02 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV03 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV04 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV05 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV06 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV07 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV09 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV10 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV12 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CV13 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV14 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV15 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CV18 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV20 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CV21 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV22 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CV26 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
D601 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D602 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D603 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
D901 0401-001097 DIODE-SWITCHING;HN2D01FU,80V,80mA,1-2T1C
D903 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
IC101 1201-001312 IC-PREAMP;CXA2032Q,QFP,32P,7.0MIL,SINGLE
IC201 1201-001322 IC-VIDEO AMP;NJM2538V,SOP,20P,175MIL,-,-
IC202 AC14-12015G IC-LINEAR;NJM2249V,SSOP,TAPE
IC401 1204-001946 IC-OSD PROCESSOR;UPD6467GR,SSOP,20P,173M
IC451 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
IC501 0909-001013 IC-REAL TIME CLOCK;5C372,8BIT,SOP,8P,-,3
IC502 1003-001241 IC-MOTOR DRIVER;LB11990W,SQPF,64P,-,-,1A
IC601 AD09-00158A IC MICOM;UPD703040GM-051-UEU,SC-L700(3?
IC602 1203-002807 IC-VOLTAGE REGULATOR;XC6413FY01MR,SOT-25
IC603 1103-001224 IC-EEPROM;524L50X51,2048x8Bit,SOP,8P,225
IC701 1201-001406 IC-AUDIO AMP;7458,SQFP,64P,393MIL,-,-,PL
IC901 1203-001534 IC-PWM CONTROLLER;TL1466I,QFP,64P,-,PLAS
CL28 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CN101 3708-001348 CONNECTOR-FPC/FFC/PIC;11P,-,SMD-A,SN
CN501 3708-001471 CONNECTOR-FPC/FFC/PIC;43P,0.5mm,SMD-A,SN
CN601 3711-004735 CONNECTOR-HEADER;BOX,38P,2R,0.8mm,SMD-A,
CN602 3708-001584 CONNECTOR-FPC/FFC/PIC;19P,1mm,SMD-A,SN
CN606 3708-001581 CONNECTOR-FPC/FFC/PIC;24P,0.5mm,SMD-A,SN
CN702 3711-002049 CONNECTOR-HEADER;BOX,6P,1R,1.25mm,SMD-A,
CNP01 3710-001478 CONNECTOR-SOCKET;18P,2R,1MM,SMD-S,SN
CNP02 3708-001575 CONNECTOR-FPC/FFC/PIC;22P,0.5mm,SMD-A,SN
CP01 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CP02 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP04 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP07 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP08 2404-001251 C-TA,CHIP;22UF,20%,7V,-,TP,3216
CP09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP11 2404-001251 C-TA,CHIP;22UF,20%,7V,-,TP,3216
CP12 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP13 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP14 2404-001251 C-TA,CHIP;22UF,20%,7V,-,TP,3216
CP15 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP16 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP17 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP19 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP20 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP21 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP22 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP24 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP25 2203-001071 C-CERAMIC,CHIP;0.056NF,5%,50V,C0G,TP,160
CP26 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP27 2203-000681 C-CERAMIC,CHIP;0.027NF,5%,50V,C0G,TP,160
CP28 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP29 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
CP31 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP34 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP35 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP36 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP37 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP38 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CP39 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
