Samsung Electronics 3-5
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
LA04 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LD01 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
LP01 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LP02 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
LP03 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
LP04 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LP05 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LP06 2703-000373 INDUCTOR-SMD;68uH,5%,2.5x2x1.8mm
LV01 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
PS901 3601-001146 FUSE-SURFACE MOUNT;63V,2A,SLOW-BLOW,EPOX
Q130 0504-001038 TR-DIGITAL;KRC402,NPN,100MW,10K/10K,SOT-
Q131 0501-002311 TR-SMALL SIGNAL;HN2A01FU,PNP,200mW,UMD6,
Q141 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q142 0501-002311 TR-SMALL SIGNAL;HN2A01FU,PNP,200mW,UMD6,
Q151 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q152 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q153 0504-001038 TR-DIGITAL;KRC402,NPN,100MW,10K/10K,SOT-
Q161 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q162 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q171 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U
Q172 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
Q173 0504-001038 TR-DIGITAL;KRC402,NPN,100MW,10K/10K,SOT-
Q186 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
Q188 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q189 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q451 0505-001726 FET-SILICON;ECH8603,P,-20V,-4A,37MOHM,1.
Q453 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q454 0504-001035 TR-DIGITAL;KRA301,PNP,100MW,4.7K/4.7K,SO
Q455 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q501 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q502 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q601 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT-
Q604 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
Q701 0501-000546 TR-SMALL SIGNAL;KSA1298,PNP,200mW,SOT-23
Q702 0504-001038 TR-DIGITAL;KRC402,NPN,100MW,10K/10K,SOT-
Q703 0501-002312 TR-SMALL SIGNAL;HN2C01FU,NPN,200mW,UMD6,
Q901 0502-001178 TR-POWER;CPH6702,PNP,1300mW,CPH6,TP,200
Q902 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500mW,PCP,TP
Q903 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
Q904 0501-000546 TR-SMALL SIGNAL;KSA1298,PNP,200mW,SOT-23
Q905 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
Q906 0502-001178 TR-POWER;CPH6702,PNP,1300mW,CPH6,TP,200
Q907 0502-001178 TR-POWER;CPH6702,PNP,1300mW,CPH6,TP,200
Q908 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500mW,PCP,TP
Q909 0502-001178 TR-POWER;CPH6702,PNP,1300mW,CPH6,TP,200
IC902 1203-002522 IC-VOLTAGE REGULATOR;1572,SOT-25A,5P,2.9
ICA01 1002-001258 IC-A/D CONVERTER;AD9806JST80016R3,10BITS
ICD01 AH14-00001A IC-DIS;KS7333,TQFP,-,80P,M-PJ
ICD02 1105-001035 IC-DRAM;416S1120,1Mx16Bit,TSOP,50P,400
ICD03 0801-000022 IC-CMOS LOGIC;7S00,NAND GATE,SOP,5P,49MI
ICL01 1201-001667 IC-OP AMP;12902,SSOP,TP,14P,173MIL,QUAD,
ICL02 1003-001200 IC-MOTOR DRIVER;UPD16835,SOP,38P,300MIL,
ICL03 AC14-12012T IC-OP AMP;TA75S01F(TE85L),QFP,-
ICP01 AD13-00010A IC-DSP;MB87L1551,W-PJ,176P,-,QFP,-,-,
ICP02 1003-001065 IC-CLOCK DRIVER;KS7221D,SOP,20P,225MIL,Q
ICV01 1204-001760 IC-VIDEO PROCESS;UPC5020GR-125,SOP,20P,3
L101 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L102 2703-000002 INDUCTOR-SMD;100uH,10%,2.5x3.2x2mm
L130 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L131 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L151 2703-000363 INDUCTOR-SMD;10uH,5%,2.5x2x1.8mm
L152 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L153 2703-000366 INDUCTOR-SMD;22uH,5%,2.5x2x1.8mm
L154 2703-000373 INDUCTOR-SMD;68uH,5%,2.5x2x1.8mm
L171 2703-000365 INDUCTOR-SMD;15uH,5%,2.5x2x1.8mm
L172 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm
L173 2703-000381 INDUCTOR-SMD;180uH,5%,3.2x2.5x2.2mm
L181 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
L186 2703-000375 INDUCTOR-SMD;82uH,5%,2.5x2x1.8mm
L187 2703-000376 INDUCTOR-SMD;8.2uH,5%,2.5x2x1.8mm
L201 2703-000409 INDUCTOR-SMD;47uH,10%,3.2x2.5x2.2mm
L203 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L401 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
L701 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
L702 2703-000002 INDUCTOR-SMD;100uH,10%,2.5x3.2x2mm
L902 2703-001871 INDUCTOR-SMD;10UH,20%,6X6X2.8MM
L903 2703-002054 INDUCTOR-SMD;47uH,20%,6x6.3x3.0mm
L904 2703-000398 INDUCTOR-SMD;10uH,10%,3.2x2.5x2.2mm
L910 2703-001871 INDUCTOR-SMD;10UH,20%,6X6X2.8MM
L911 2703-001910 INDUCTOR-SMD;68uH,20%,6x6x2.8mm
L912 2703-001910 INDUCTOR-SMD;68uH,20%,6x6x2.8mm
L913 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L914 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L915 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L916 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L918 2703-002054 INDUCTOR-SMD;47uH,20%,6x6.3x3.0mm
L923 2703-002054 INDUCTOR-SMD;47uH,20%,6x6.3x3.0mm
LA01 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LA02 2703-001883 INDUCTOR-SMD;22uH,10%,2.5x2x1.8mm
LA03 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
