Samsung SCL810 - Page 73

Samsung Electronics3-6
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
Q910 0502-001178 TR-POWER;CPH6702,PNP,1300mW,CPH6,TP,200
Q911 0501-000546 TR-SMALL SIGNAL;KSA1298,PNP,200mW,SOT-23
Q912 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
Q915 0501-000546 TR-SMALL SIGNAL;KSA1298,PNP,200mW,SOT-23
Q916 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
Q919 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q923 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
Q926 0504-001035 TR-DIGITAL;KRA301,PNP,100MW,4.7K/4.7K,SO
Q927 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
QA01 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QA02 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QA05 0504-001040 TR-DIGITAL;KRC403,NPN,100MW,22K/22K,SOT-
QP01 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QP02 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QP03 0501-002128 TR-SMALL SIGNAL;KTC4075,NPN,100mW,USM,TP
QP38 0504-001032 TR-DIGITAL;KRC404,NPN,100MW,47K/47K,SOT-
QV01 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QV02 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QV03 0501-002171 TR-SMALL SIGNAL;KTA2014,PNP,100mW,SOT-32
QV06 0501-000596 TR-SMALL SIGNAL;2SB970R,PNP,200mW,SOT-23
R101 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
R102 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R103 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R104 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R105 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R106 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
R110 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R111 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R112 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R114 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R115 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R116 2007-000129 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608
R117 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R118 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R119 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
R120 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R121 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R124 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R130 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R132 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R134 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R135 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R137 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
R140 2007-000129 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608
R141 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R142 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R143 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R144 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R145 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R147 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R148 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R149 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R151 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
R152 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R153 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R154 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R155 2007-000643 R-CHIP;270ohm,5%,1/16W,DA,TP,1608
R158 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
R159 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R160 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R161 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R162 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R163 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R164 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R167 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
R168 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R169 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R170 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R171 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
R172 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
R173 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R174 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R175 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R176 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R177 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R178 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R179 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
R180 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
R181 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
R182 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R183 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R187 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
R188 2007-000118 R-CHIP;390ohm,5%,1/16W,DA,TP,1608
R189 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R190 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R191 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R192 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R193 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R194 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R195 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
