Samsung SCL810 - Page 77

Samsung Electronics3-10
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RL25 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RL26 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RL27 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL28 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RL29 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RL30 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL31 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL32 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RL33 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RL34 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RL35 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RL38 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
RL39 2007-000450 R-CHIP;180ohm,5%,1/16W,DA,TP,1608
RL43 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RP06 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP07 2007-001042 R-CHIP;56ohm,1%,1/16W,DA,TP,1608
RP08 2007-001042 R-CHIP;56ohm,1%,1/16W,DA,TP,1608
RP09 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP10 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP11 2007-000287 R-CHIP;100OHM,1%,1/10W,DA,TP,1608
RP12 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP13 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RP15 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RP16 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP17 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RP18 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RP19 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
RP20 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP21 2007-000120 R-CHIP;680ohm,5%,1/16W,DA,TP,1608
RP23 2007-000040 R-CHIP;150ohm,1%,1/16W,DA,TP,1608
RP24 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
RP25 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
RP26 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP27 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP28 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP29 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RP30 2007-001090 R-CHIP;620ohm,1%,1/16W,DA,TP,1608
RP300 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP302 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP31 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP32 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP33 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RP34 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
RP35 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RP36 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP37 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RP38 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RP50 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RP51 2007-000287 R-CHIP;100OHM,1%,1/10W,DA,TP,1608
RP52 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP53 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP55 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP56 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RV01 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV02 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV03 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV04 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV05 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RV06 2007-000099 R-CHIP;62Kohm,5%,1/16W,DA,TP,1608
RV07 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RV12 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RV14 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RV15 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV16 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RV17 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RV18 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RV19 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV20 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV21 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RV24 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RV31 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RV32 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
SW601 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW602 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW603 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW606 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
SW607 3404-001034 SWITCH-TACT;12V,50mA,160gf,4x7.4x1.8mm,S
T901 AD26-00024A TRANS POWER;CLQ52,W2-PJ,42UH,8P,6~9V,15V
X601 2801-004146 CRYSTAL-SMD;20MHZ,30PPM,SX-3,18PF,30OHM,
X602 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12.5
XP01 2801-004141 CRYSTAL-SMD;28.636MHZ,18PPM,28-ABL,7.0PF
ASSY-REAR BOARD;-,W2-PJ,HI8
CN451 3710-001676 CONNECTOR-SOCKET;38P,2R,0.8mm,SMD-S,SN
CN452 3710-001479 CONNECTOR-SOCKET;14P,2R,1MM,SMD-S,SN
D451 0601-001418 LED;SMD,AMB,-,610nm
Q451 0504-001037 TR-DIGITAL;KRC401,NPN,100MW,4.7K/4.7K,SO
R451 2007-000072 R-CHIP;47ohm,5%,1/16W,DA,TP,1608
R452 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R466 2007-007948 R-CHIP;0.1ohm,1%,0.75W,DA,TP,5025
