Samsung Electronics 3-11
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
R472 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R473 2007-000071 R-CHIP;22ohm,5%,1/16W,DA,TP,1608
R478 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
SW471 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SW473 3404-001117 SWITCH-TACT;12V,50mA,130gf,8.0x3.7x2.5mm
SW474 3404-001119 SWITCH-TACT;12V,50mA,130gf,6.2x6.2x2.6mm
SW477 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
SW478 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE
VR471 2102-001019 VR-SLIDE;10Kohm,30%,1/20W,SLIDE
J452 AD97-01200A ASSY-S-JACK;M1-PJ,-,-
J452 AD97-03052A ASSY-DC JACK;3P,W-PJ,DDSE-0056
J453 3722-001202 JACK-PHONE;7P,3.6PI,AG,YEL,NO
ASSY-EVF BOARD;0.24,W3-PJ,NTSC
CE01 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE03 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE04 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CE05 2404-000284 C-TA,CHIP;10uF,20%,16V,-,TP,3528,-
CE07 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE08 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE10 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE12 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE13 2203-000975 C-CERAMIC,CHIP;47nF,10%,25V,X7R,TP,1608,
CE14 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CE15 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
CE16 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CE17 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE18 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE19 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE20 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CNE01 3708-001680 CONNECTOR-FPC/FFC/PIC;6P,0.5MM,SMD-A,SN
CNE02 3708-001076 CONNECTOR-FPC/FFC/PIC;20P,0.5MM,SMD-S,SN
DE02 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
DE03 0404-000110 DIODE-SCHOTTKY;RB411D,20V,500mA,SOT-23,T
DE04 0403-001421 DIODE-ZENER;KDZ2.7V,2.5-2.9V,150MW,SOD-3
ICE01 1003-001373 IC-LCD DRIVER;MCVVQ111FB,LQFP,48P,276MIL
LE01 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LE03 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
LED01 0601-001586 LED;CHIP,WHT,-,470NM
QE02 0501-002310 TR-SMALL SIGNAL;HN1B04FU,PNP/NPN,200mW,U
RE01 2007-001125 R-CHIP;68Kohm,1%,1/16W,DA,TP,1608
RE02 2007-001068 R-CHIP;6.8Kohm,1%,1/16W,DA,TP,1608
RE05 2007-000772 R-CHIP;33Kohm,1%,1/16W,DA,TP,1608
RE06 2007-000828 R-CHIP;39Kohm,1%,1/16W,DA,TP,1608
RE07 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RE16 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RE17 2007-000082 R-CHIP;3.3Kohm,5%,1/16W,DA,TP,1608
RE20 2007-000090 R-CHIP;10KOHM,5%,1/16W,DA,TP,1608
RE21 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RE22 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RE25 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RE26 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RE29 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RE30 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RE31 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
VRE02 2104-001007 VR-SMD;10Kohm,25%,0.15W,TOP
ASSY-LCD BOARD;2.5,W4-PJ,PAL
CL101 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL102 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL103 2301-001108 C-FILM,CHIP;22nF,5%,50V,TP,3.2x2.5x1.4,3
CL104 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL105 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL106 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL107 2404-001131 C-TA,CHIP;22UF,10%,10V,GP,TP,3528
CL108 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL109 2203-005046 C-CERAMIC,CHIP;0.022nF,5%,3kV,NP0,TP,452
CL201 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL202 2404-000212 C-TA,CHIP;3.3uF,20%,25V,-,TP,3528,-
CL203 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL204 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL205 2203-000483 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CL206 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL207 2404-000157 C-TA,CHIP;1uF,20%,35V,-,TP,3216,-
CL208 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CL209 2203-000815 C-CERAMIC,CHIP;0.033NF,5%,50V,C0G,TP,160
CL210 2203-000998 C-CERAMIC,CHIP;0.047NF,5%,50V,C0G,TP,160
CL211 2404-001020 C-TA,CHIP;10uF,20%,10V,GP,TP,3216,3.2
CL212 2203-002793 C-CERAMIC,CHIP;1000nF,+80-20%,25V,Y5V,TP
CNL101 3708-001603 CONNECTOR-FPC/FFC/PIC;24P,0.5MM,SMD-A,SN
CNL102 3708-001334 CONNECTOR-FPC/FFC/PIC;10P,0.8mm,SMD-A,SN
CNL201 3708-001690 CONNECTOR-FPC/FFC/PIC;28P,0.5MM,SMD-A,SN
DL201 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
ICL201 0801-002732 IC-CMOS LOGIC;TC7WT126FU,INVERTER,SSOP,8
ICL202 0801-002733 IC-CMOS LOGIC;TC7WT125FU,BUFFER,SSOP,8P,
ICL203 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SSOP,8P,110M
LL101 2703-000396 INDUCTOR-SMD;10uH,10%,2.5x2x1.8mm
