Samsung SCX-4216F Series User Manual

5-19
Exploded Views and Parts List
< Fuser Ass’y Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
O: Service available X: Service not available
0 ELA HOU-FUSER 110V JC96- 1
1 COVER-FUSER J C63-00105A 1
2 HOLDER-PLATE CLAW JC61-00584A 4
3 SPRING ETC-CLAW JC61-00064A 4
4 PMO-ROLLER EXIT JC72-60059A 2
5 SPRING-EXIT F_UP JC61-70976A 2
6 THERMOSTAT-150 JC47-00005A 1
7 PMO-GEAR_EXIT_DRV16 JC72-00143A 1
8 GEAR-IDLE 23 JC66-00396A 1
9 RING-CS 6044-000001 1
10 GEAR-RDCN 2515 JC66-00397A 1
11 IPR-ELECTRODE_LAMP JC70-00275A 1
12 ELECTRODE-WIRE_L JC70-00450A 1
13 THERMISTER-NTC HF 1404-001298 1
14 ELECTRODE-WIRE_R JC70-00449A 1
15 CBF HARNESS-FUSER(1) JC39-00239A 1
16 GEAR-FUSER_HTN JC66-00564A 1
17 BUSH-HR_L JC61-00589A 1
18 NPR-ROLLER_HEAT JC66-00601A 1
19 BUSH-HR_R JC61-00590A 1
20 LAMP-HALOGEN(110V) 4713-001155 1 110V
21 ROLLER-EXIT F_UP JC66-00380A 1
22 MEC-ROLLER_PR(1400) JC66-00600A 1
23 BEARING-PRESSURE JC66-10901A 2
24 SPRING-PR(1400) 6107-001168 2
25 PMO-BUSHING TX JC72-00382A 3
26 HOLDER-ACTUATOR JC61-00581A 1
27 PMO-ACTUATOR_EXIT JC72-00987A 1
28 IPR-FRAME_FUSER JC70-00317A 1
29 GUIDE-INPUT JC61-00595A 1
31 RMO-RUBBER_EXIT JC73-00017A 2
33 LABEL(P)-CAUTION, HOT_FUSER JC68-30928D 1
30 SPRING ETC-ACT_EXIT 6107-001165 1
32 NUT-HEXAGON 6021-000222 5
?? NEW-CLAW ASSY TBD
?? PLATE-CLAW JC61-00605A 4

Samsung SCX-4216F Series Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Modem Speed	33.6 Kbps
Paper Input Capacity	250 sheets
Memory	8 MB
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	4800 x 4800 dpi (enhanced)
Connectivity	USB
