Samsung SCX-4216F Series User Manual

5-1
5. Exploded Views and Parts List
5-1 Main Assembly Exploded view ............................................................................... page(5-2)
5-2 ADF Assembly Exploded view ................................................................................ page(5-5)
5-3 PLATEN COVER Assembly Exploded view ........................................................... page(5-8
5-4 OPE Assembly Exploded view ................................................................................ page(5-10)
5-5 Scanner Assembly Exploded view ......................................................................... page(5-12)
5-6 Frame Ass’y Exploded view .................................................................................... page(5-14)
5-7 Rx Drive Ass’y Exploded view ................................................................................ page(5-17)
5-8 Fuser Ass’y Exploded view ..................................................................................... page(5-18)
5-9 Cassette Ass’y Exploded view ................................................................................ page(5-20)
5-10 SCREWS ................................................................................................................... page(5-22)
5-11 SMPS PARTS.............................................................................................................page(5-22)

Samsung SCX-4216F Series Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Modem Speed	33.6 Kbps
Paper Input Capacity	250 sheets
Memory	8 MB
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	4800 x 4800 dpi (enhanced)
Connectivity	USB
