Samsung SCX-4216F Series User Manual

5-9
Exploded Views and Parts List
0 MEA-COVER PLATEN(4IN1) JC97-01780A 1
1 COVER-M-PLATEN(4IN1) JC63-00146A 1
2 WHITE SPONGE WHITE SPONGE 1
3 MEA-TX STACKER ASS’Y JB97-01544A 1
3-1 PMO-TX STACKER JB72-01166A 1
3-2 PMO-DOC GUIDE(L) JB72-01171A 1
3-3 GEAR-PINION JG66-40003A 1
3-4 PMO-DOC GUIDE(R) JB72-01170A 1
5 ROLLER-M-EXIT IDLE JC66-00462A 2
6 SHAFT-STACKER TBD 2
7 MEA-RACK HINGE(4IN1) JC97-01707A 2
8 PMO-ROLL PINCH JG72-40663A 2
9 ICT-SHAFT PINCH JF70-40521B 1
10 SPRING ETC-FEED JC61-00011A 2
11 SPRING ETC-EXIT LOWER IDLE JC61-00484A 4
? SHAFT-IDLE FEED JC66-00558A 1
? GUIDE-STACKER SUB JC61-00712A 1
<
COVER PLATEN Unit Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
O: Service available X: Service not available

Samsung SCX-4216F Series Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Modem Speed	33.6 Kbps
Paper Input Capacity	250 sheets
Memory	8 MB
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	4800 x 4800 dpi (enhanced)
Connectivity	USB
