Samsung SCX-4216F Series User Manual

5-15
Exploded Views and Parts List
< Frame Ass’y Parts List >
SA. : Service Available
NO DESCRIPTION SEC CODE Q’TY SA REMARK
O: Service available X: Service not available
0 ELA UNIT-FRAME ASSY 220V TBD 1
1 FRAME-Base JC61-00579A 1
2 GUIDE-TR JC61-00607A 1
3 PLATE-SAW JC61-00604A 1
4 GUIDE-TR RIB JC61-00594A 1
5 PMO-GEAR_EXIT_DRV16 JC72-00143A 1
6 RING-CS 6044-000001 1
7 RMO-RUBBER_FOOT JC73-00027A 1
8 IPR-GROUND TR JC70-00311A 1
9 MEC-TERMINAL JC75-00049A 1
10 IPR-TERMINAL CON JC70-00312A 1
11 IPR-TERMINAL CR JC70-00313A 1
12 HOUSING-TERMINAL JC61-00592A 1
13 PMO-Locker cst JC72-00983A 1
14 PMO-ACTUATOR CVR OPEN JC72-00974A 1
15 PMO-PLATE GUIDE DEVE_R JC72-00985A 1
16 SPRING-GUIDE DEVE JC61-00038A 2
17 IPR-GROUND_ROLLER IDLE JC70-00315A 1
18 PMO-PLATE GUIDE DEVE_L JC72-00984A 1
19 PMO-ACTUATOR FEED JC72-00976A 1
20 PMO-ACTUATOR EMPTY JC72-00975A 1
21 PMO-ACTUATOR MANUAL JC72-00977A 1
22 IPR-GROUND EARTH TR JC70-00309A 1
23 SPRING-TR_R TBD 1
24 ROLLER-FEED JC66-00379A 1
25 PMO-BUSHING TX JC72-00382A 1
26 SHAFT-FEED JC66-00398A 1
27 TBD 1
27-1 BUSH-PICK_UP_L JC61-00586A 1
27-2 SHAFT-PICK_UP JC66-00399A 1
27-3 STOPPER-PICK_UP JC61-00593A 1
27-4 PMO-IDLE PICK_UP JC72-00982A 1
27-5 HOUSING-PICK_UP JC61-00591A 1
27-6 BUSH-PICK_UP_R JC61-00587A 1
28 IPR-EARTH TRANSFER JC70-00307A 1
29 HOLDER-PTL JC61-00583A 1
30 LENS-PTL JC67-00027A 1
31 BUSH-TR_L JC61-00588A 1
32 SPRING-TR_L JC61-00024A 1
33 ROLLER-FEED ROLLER 1 TBD 1
34 PMO-BUSHING TR_L JC72-00102A 1
35 IPR-GROUND FUSER JC70-00310A 1
36 SHAFT-FEED IDLE JC66-00527A 1

Samsung SCX-4216F Series Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Fax Modem Speed	33.6 Kbps
Paper Input Capacity	250 sheets
Memory	8 MB
Print Speed	16 ppm
Copy Speed	16 cpm
Scan Resolution	4800 x 4800 dpi (enhanced)
Connectivity	USB
