Samsung SF-340 - Page 5

Service Manual
Exploded View & Parts List
8-4
Samsung Electronics
Main Assembly Parts List
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
9 SMPS-RHINE_2 (V1) JB44-00035A 1 O 110V
SMPS-RHINE_2 (V2) JB44-00036A 1 O 230V
SMPS-RHINE_2 (V2) China JB44-00037A 1 O 230V
10 CBF HARNESS-SMPS-MAIN JB39-00177A 1 O
11 MEA UNIT-ASF JB97-01621E 1 O
12 ELA UNIT-BASE (BASIC) JB96-01539A 1 O SF-340
ELA UNIT-BASE (TAD) JB96-01542A 1 O SF-345TP
ELA UNIT-BASE (P) JB96-01558A 1 O SF-341P
13 MEA HOU-STACKER TX JB97-01624B 1 O
13-1 TRAY-M_STACKER TX1 JB63-00065D 1 O
13-2 TRAY-M_STACKER TX2 JB63-00047D 1 O
14 COVER-M_FLIP JB63-00222A 1 O
15 ELA UNIT-OPE (BASIC) *Appendix 1 O
15-1 ELA HOU-OPE *Appendix 1 O
16 CHUTE-M_DOC JB61-00358A 1 O
17 ELA HOU-SIDE L JB96-01549A 1 O SF-340
ELA HOU-SIDE L (TP) JB96-01549B 1 O SF-345TP
ELA HOU-SIDE L (P) JB96-01549C 1 O SF-341P
17-1 COVER-M_SIDE L JB63-00215A 1 O SF-340
COVER-M_SIDE L JB63-00215B 1 O SF-345TP
17-2 SPEAKER 3001-001293 1 O
18 COVER-M_SIDE R JB63-00214A 1 O SF-340
COVER-M_SIDE R (TP) JB63-00214B 1 O SF-341P/345TP
19 MEA ETC-ROLLER WHITE JB97-01207A 1 O
19-1 MEA-ROLLER WHITE JB75-00053A 1 O
19-2 PMO-BUSHING WHITE JB72-00137A 1 O
19-3 GEAR-DRIVE JB66-00004A 1 O
* Appendix : see appendix table
