Samsung SF-340 - Main Assembly Parts List

Exploded View & Parts List
Service Manual
8-3
Samsung Electronics
Main Assembly Parts List
SA : Service Available
O : Service available X : Service not available
No. Description SEC.Code Q’ty SA Remark
0 SET SF-340/341P/345TP
1 MEA HOU-COVER TOP JB97-01840A 1 O SF-340
MEA HOU-COVER TOP (T) JB97-01840B 1 O SF-345TP
MEA HOU-COVER TOP (P) JB97-01840C 1 O SF-341P
1-1 COVER-M-TOP JB63-00220A 1 O
1-2 MEA-HOU DOOR JB97-01835A 1 O SF-340
MEA-HOU DOOR (T) JB97-01835B 1 O SF-345TP
MEA-HOU DOOR (P) JB97-01835C 1 O SF-341P
1-2-1 COVER-M_DOOR JB63-00221A 1 O SF-340
COVER-M_DOOR (T) JB63-00221C 1 O SF-345TP
COVER-M_DOOR (P) JB63-00221D 1 O SF-341P
1-2-2 GUIDE-M_DOC L JB61-00357A 1 O SF-340
GUIDE-M_DOC L (T) JB61-00357B 1 O SF-345TP
GUIDE-M_DOC L (P) JB61-00357C 1 O SF-341P
1-2-3 GUIDE-M_DOC R JB61-00356A 1 O SF-340
GUIDE-M_DOC R (T) JB61-00356B 1 O SF-345TP
GUIDE-M_DOC R (P) JB61-00356C 1 O SF-341P
1-3 BUTTON-M_HOOK SWICH JB64-00065A 1 O
1-4 SPRING ETC-LEVER JB61-70908A 1 O
2 ELA UNIT-HANDSET JB96-01535A 1 O SF-340
ELA UNIT-HANDSET (TP) JB96-01535B 1 O SF-341P/345TP
3 CBF HARNESS-CR MOTOR-MAIN JB39-00179A 1 O
4 SHEET-INSULATION LIU JB63-00059A 1 O
5 LIU PBA JB92-01248A 1 O SF-340, UK
LIU PBA JB92-01248B 1 O SF-345TP, UK
LIU PBA JB92-01248C 1 O SF-341P, CHINA
LIU PBA JB92-01248D 1 O SF-340, CHINA
LIU PBA JB92-01248E 1 O SF-345TP, RUSSIA
LIU PBA JB92-01248H 1 O SF-340, USA
LIU PBA JB92-01248I 1 O SF-349TP, RUSSIA
LIU PBA JB92-01248J 1 O SF-345TP, USA
LIU PBA JB92-01248K 1 O
SF-345TP, GERMANY
6 CBF HARNESS-MAIN LIU FFC JB39-00181A 1 O
7 ELA UNIT-ENGINE JB96-01540A 1 O
8 PBA MAIN JB92-01247A 1 O SF-340
PBA MAIN JB92-01247B 1 O SF-345TP
PBA MAIN JB92-01247C 1 O SF-341P
* Appendix : see appendix table
