Exploded View and Parts List
7-2
This Document can not be used without Samsung's authorization
5 6
7 8
1) Disjoint in Front with picture pressing
top portion FRONT's Hinge by tweezers.
1) After catch the REAR and press the PBA
SHIELD CAN, lift REAR.
1) After open the folder and catch the
FRONT, press KEYPAD part and softly lift
PBA.
2) Disjoint PBA and KEYPAD.
1) Lift below the SCREW BOSS HOLE part.
1) Be careful REAR damage when you Disjoint a REAR.
1) When disjoint CONNECTOR, be careful approximately
parts damage.
1) Be careful FRONT LOCKER damage.
1) Be careful FRONT plastic, FRONT SUS and Hinge
damage.
