Exploded Views and Parts List
6-2
Samsung Electronics
■
Parts List
No.
1 DB92-00035M ASSÕY FRONT PANEL ASSÕY 1 1 1 MODEL:*A*
DB92-00179A ASSÕY FRONT PANEL ASSÕY 1 1 1 MODEL:*B*
1-1 DB64-00127A GRILLE AIR INLET HIPS 1 1 1 MODEL*A*
DB64-00278A GRILLE AIR INLET HIPS 1 1 1 MODEL*B*
2 DB63-30150C GUARD AIR FILTER PP 2 2 2
3 DB74-10101C CLEANER FILTER ASSÕY ASSÕY 1 1 1 OPTION
3-1 DB61-10164B CASE CLEANER FILTER PP 2 2 2 OPTION
3-2 DB74-10082A DEODORIZING FILTER POLYESTER/CARBON 1 1 1 OPTION
3-3 DB74-10081A CLEANER FILTER POLYESTER/COTTON 1 1 1 OPTION
4 DB63-00091A COVER TERMINAL ABS(VO) 1 1 1
5 DB63-00115A COVER DISPLAY ABS(BLK) 1 1 1
6 DB93-00311C ASSÕY PCB DISPLAY ASSÕY 1 1 1
7L DB94-00029B ASSÕY TRAY DRAIN ASSÕY 1 1 1
DRAIN:LEFTSIDE
7R DB94-00099A ASSÕY TRAY DRAIN ASSÕY 1 1 1
DRAIN:RIGHTSIDE
7-1 DB31-10153 B ASSÕY STEPING MOTOR STEEPING 1 1 1
7-2 DB66-00104A BLADE-H ABS 1 1 1
8 DB75-40087G ASSÕY EVAP PLATE1.2(5/8Ó) 1 1 -
DB75-40087F ASSÕY EVAP SLIT1.5(1/2Ó) - - 1
9 DB67-30089E ASSÕY SPACER PVC 1 1 1
10L DB90-00140B ASSÕY HOLDER MOTOR ASSÕY 1 1 -
DRAIN:LEFTSIDE
10L DB90-00375A ASSÕY HOLDER MOTOR ASSÕY - - 1
DRAIN:LEFTSIDE
10R DB90-00140K ASSÕY HOLDER MOTOR ASSÕY 1 1 -
DRAIN:RIGHTSIDE
10R DB90-00433B ASSÕY HOLDER MOTOR ASSÕY - - 1
DRAIN:RIGHTSIDE
10-2 DB65-10108A CLIP EARTH WIRE SECC 1 1 1
10-3 DB65-00039B TERMINAL BLOCK ASSÕY 6P,25A 1 1 -
DB65-00068A TERMINAL BLOCK ASSÕY 6P,25A - - 1
11 DB31-10151C MOTOR FAN IN IC-9430SKC7A 1 1 1
12 DB94-00040C ASSÕY C-F-FAN ¿95xL 1 1 1
13 DB90-40135B ASSÕY HOLDER BEARING ASSÕY 1 1 1
14 PD-TQ24A1R-01 ASSÕY MAIN PCB PD-T24A1R-01 1 1 -
PE-S1450R-01 ASSÕY MAIN PCB PE-S1470-01 - - 1
15 DB32-00027B ASSÕY TERMISTOR 103AT 1 1 1
16 DB61-10163A CASE CONTROL ABS(VO) 1 1 1
17L DB94-20037H ASSÕY BACK BODY ASSÕY 1 1 1
17R DB94-00107A ASSÕY BACK BODY ASSÕY 1 1 1
18L DB90-00163A HOLDER PIPE PP 1 1 1
18R DB90-00434A HOLDER PIPE PP 1 1 1
19 DB70-10663A PLATE HANGER SGCC-M 1 1 1
CODE NO Description Specification Remarks
QÕTY
AST24✳5(6)RE/B
SC24TS5
AST18✳9(0)RE/B
AS18✳9(0)RE/D
SC18ZS9
10-00115A(3)-EV 3/8/01 10:38 AM Page 6-2
