8-2 ASSÕY DISPLAY & Module
¥ASSÕY DISPLAY & MODULE PCB : DB93-00311C
Description
NO
PCB-DISPLAY
LED-LAMP
LED-LAMP
MODULE REMCOON
C-CERAMIC
C-CERAMIC
R-CARBON
DIODE SWITCHING
JUMP-WIRE
CONNECTOR WAFER
COVER DISPLAY UP
1
2
3
4
5
6
7
8
9
10
11
Specification
FR-1 T1.6
SY5511(YEL)
S05511(ORG)
PNA4612MOOHB
CA 0A 50V 102Z
CA 0A 50V 104Z
RD 1/4 TP 471-J
1N4148
10mm
SMAW200-10P
ABS BLK
QÕTY
1
1
5
1
1
1
3
1
3
1
1
