29
Control Codes
Viewing control state (Get control command)
Header Command ID Data length Checksum
0xAA Command type 0
Controlling (Set control command)
Header Command ID Data length Data Checksum
0xAA Command type 1 Value
Command
No. Command type Command Value range
1
0x11 0~1
2
Volume control 0x12 0~100
3
Input source control 0x14 -
4
Screen mode control 0x18 -
5
Screen size control 0x19 0~255
6
PIP on/off control 0x3C 0~1
7
only)
0x3D 0
8
0x5C 0~1
9
Safety Lock 0x5D 0~1
10
Video Wall On 0x84 0~1
No. Command type Command Value range
11
Video Wall User Control 0x89 -
Header Command ID Data length Data 1 Checksum
0xAA 0x11 1
Header Command ID Data length Data 1 12
0xAA 0x11 1 1
