PIP On/Off control
 Function




Video Wall is set to On.

MagicInfo.
 
Header Command ID Data length Checksum
0xAA 0x3C 0
 Setting PIP on/off (Set the PIP ON / OFF)
Header Command ID Data length Data Checksum
0xAA 0x3C 1 "PIP"
"PIP": A code used to turn the PIP mode of a product on or off


 Ack
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x3C "PIP"
"PIP": A code used to turn the PIP mode of a product on or off
 Nak
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x3C "PIP"

Auto adjustment control (PC and BNC only)
 Function

 
None
 
Header Command ID Data length Data Checksum
0xAA 0x3D 1 "Auto


 Ack
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x3D "Auto

 Nak
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x3D "ERR"

