34
Video Wall On
 Function
Turn Video Wall on or off on the product from your computer.
 Get Video Wall On/Off Status
Header Command ID Data length Checksum
0xAA 0x84 0
 Set Video Wall On/Off
Header Command ID Data length Data Checksum
0xAA 0x84 1 V.Wall_On
 


 Ack
Header Command ID Data length Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x84 V.Wall_On

 Nak
Header Command ID Data
length
Ack/Nak r-CMD Val1 Checksum
0xAA 0xFF 3  0x84 ERR

Video Wall User Control
 Function
Turn the Video Wall function on or off on the product from your computer.
 Get Video Wall Status
Header Command ID Data length Checksum
0xAA 0x89 0
 Set Video Wall
Header Command ID Data
length
Val1 Val2 Checksum
0xAA 0x89 2  Wall_SNo

