Alarm Setting
Alarm Enable OFF
②Alarm Input
③Alarm Output
④Aux Output
ALM MOD P SEQ. NO
IN1 OFF 1 OFF
IN2 OFF 2 OFF
IN3 OFF 3 OFF
IN4 OFF 4 OFF
Main Menu
①Camera Setting
②Sequence Setting
③P/T Setting
④OSD Setting
⑤Alarm Setting
⑥Initialize
Status
➡
➡
25. Alarm Setting
25.1. Setting Up Alarm Input
 ▶
Main Menu/Alarm Setting/Alarm Input
Alarm Enable
:
- On/Off : Enables or disables the Alarm function.
MOD
:
Enables selecting an Alarm Input method.
- NO (Normally Open)
- NC (Normally Closed)
Alarm Setting
⇨
IN 1.2.3.4
ALM GND
ALARM OFF
IN 1.2.3.4
ALM GND
ALARM ON
⇨
IN 1.2.3.4
ALM GND
ALARM ON
IN 1.2.3.4
ALM GND
ALARM OFF
P (Priority)
:
Set the priority of Alarm Inputs. If more than one alarm is simultaneously activated,
the alarm with the highest priority activates before the others. Once the alarm is canceled, the
next highest priority alarm activates.
SEQ
:
Enables setting up a sequence action for the camera in response to an alarm. Available
sequence actions are Preset, Swing, Group, Tour, Trace and A.Pan.
•Asshowninthepictureabove,theAlarmInputmustbeenteredwiththeOpenandClose
switch signals. Supplying power without entering the signals may damage the product.
Notes
Functional Description Functional Description
