Samsung SRF644CDLS - Detach the Flexzone Drawer

Installation
English32
Installation
Detach the FlexZone™ drawer
1. Lift up to remove the FlexZone™ basket.
2. Remove the wire cover with harness
using a at-head screwdriver.
3. Press the locking tab to disconnect the
wire connector.
4. Remove the hex-head bolt from each
side using a socket wrench (10 mm) or
a screwdriver.
