Page #10 background imageLoading...
Page #10 background image
1) Capacity : AC 230V/2500W (SWF-P14:2000W)
2) Location : Bottom of TUB
3) Function : Raise the water temperature
supplied at the wash process.
4) Resistance value :
5) Thermal Fuse : 128°C
Model Code No. Solenoid Coil Resistance
All Model DC61-00115A 210
±
10%
SWF-P14 23~29
SWF-P12
SWF-P10 20.5~21.5
SWF-P8
7. Designation of Main Components
7-1 Normal / Reverse Revolution of Motor and R. P. M. Control
7-2 Door safety Device
7-3 Heater
10
+
-
89
510
Rotor
Stator coil
CW
+
-
89
5
5
10
Rotor
Stator coil
CCW
<Figure1> <Figure2>
123456
789
10
STATOR
WASHING MOTOR
TACHO
HIGH-SPEED
STATOR
PROTECTOR
MIDDLE-SPEED
ROTOR
(150 C)
12A 125~250V AC
(
±
7%) STATOR(5.10) STATOR(5.1) ROTOR(8.9) TACHO(3.4) PROTECTOR(6.7) H(mm) Code-No Remark
Resistance value 2.07 0.90 2.35 42.7 0 45 DC31-00002C B
Rated value 220~240V / 50Hz
Thermistor
Solenoid
H
<Figure3>
