➃
➄ ➁
➂
➃
①
10. Tools for Disassembly and Assembly
NO. TOOL
① Box driver 10mm Heater (1)
13mm Motor (1), Balance (5)
17mm 2 holes of each left and right of the shock absorber
19mm 1 Pulley hole
➁ Double-ended 10, 13 Replaceable for the box driver.
spanner 17, 19mm Since the bolt runs idle when the box driver is used, use the box
driver 17mm.
➂ Vice pliers Tool to protect the idle and abrasion of the bolt for the box driver.
➃ Other
(Driver, Nipper, Long nose)
General tools for the after service.
➄ JIG for the Tub 1 (Disassemble and Assemble)
To Next Page
