8-1. WB : ASSY-PCB Part List
SWF-P14/P12/P10/P8
NO. Part Code Code No. Q'ty Description Specificatio Remark
1 WB002 1401-001007 1 THYRISTOR-TRIAC 10A,SM10LZ47(TOSHIBA) TRIAC1
2 WB002 1401-001024 5 THYRISTOR-TRIAC 2A,SM2LZ47(TOSHIBA) TRIAC 2~6
3 WB003 0402-001023 1 DIODE-BRIDGE RBV1506,600V,15A,SIP-4 BD1
4 WB004 3501-001156 2 RELAY-POWER 12VDC,0.53W,16000MA,1FORMA RELAY 1~2
5 WB004 3501-001157 3 RELAY-POWER 12VDC,0.53W,16000MA,1FORMC RELAY 3~5
6 WB004 3501-001007 1 RELAY 12Vdc,200mW,5A,(TAKAMISAYA) RELAY6
7 WA010 DC26-00005B 1 TRANS-FORMER 450MA,220~240VAC,11VDC TRANS
8 WB003 0402-000137 6 DIODE-RECTIFIER 1N4007,1000V,1A
D07,D11,D15~D19
D23
9 WB003 0403-000509 1 DIODE-ZENER MTZJ5.6B,5.6V,5.45-5.73V ZD1
10 WB006 0502-000288 1 TR-POWER KSD288,NPN,25W,TO-220 TR14
11 WB006 0501-000389 2 TR-SMALL SIGNAL KSC815,NPN,400mW TR1,TR2
12 WB007 1203-000515 1 IC-VOL. DETECTOR 7042,TO-92,3P IC3
13 WB008 2802-001058 1 RESONATOR-CERAMIC 8MHz,0.2%,TP,10x5x8mm RESO
14 WB007 DE13-20017A 3 IC-DRIVE KID65003AP,DIP,16P,STICK IC1,IC5,IC6
15 WB007 1103-001160 1 IC-EEPROM 4C010,128X8BIT,DIP,8P IC4
16 WB009 DE30-20016A 1 BUZZER CBE2220BA,STICK BZ
17 WB010 3404-001022 7 SWITCH-TACT 15V,20mA,130°
±
40gf,6x6x5mm SW 1~8
18 WB011 DE07-20040A 16 LED LAMP SLH-34VC70F,RED,T,PI5
19 WB012 0703-001056 1 LED DISPLAY Y-GRN,4dig,7seg,46X19X24.6mm
To Next Page
