12-1. WD : ASSY-TUB - Parts List
NO Location No Description Code No Q'ty P8 P10 P12 P14 SVC Part
1 WDD01 ASSY-WIRE DIAPHRAGM DC91-12078A 1 ●●●● ❍
2 WDD02 DOOR-DIAPHRAGM DC61-20219A 1 ●●●● ❍
3 WDD03 ASSY-CLAMP DIAPHGRAM DC97-00850A 1 ●●●● ❍
4 WDD04 BOLT-W.MOTOR DC60-40138A 3 ●●●● ❍
5 WZ008 WASHER-PLAIN DC60-60044B 6 ●●●●
6 WZ009 WASHER-NYLON DC60-60040A 3 ●●●●
7 WDD05 WEIGHT-BALANCER(L) DC66-60154A 1 ●●●● ❍
8 WZ010 BAND RING DC65-60125A 1 ●●●●
9 WDD06 HOSE-DRAWER TUB DC62-10305A 1 ●●●● ❍
10 WZ011 BOLT-HEX DC60-40140A 2 ●●●●
11 WZ012 BOLT-FLANGE DC60-40132B 1 ●●●●
12 WD007 HOSE-AIR DC62-10303A 1 ●●●●
13 WDD07 WEIGHT-BALANCER(U) DC66-60153A 1 ●●●● ❍
14 WD006 PULLEY DC66-10176B 1 ●●●● ❍
15 WZ014 WASHER-SPRING DC60-60049A 1 ●●●●
16 WZ013 NUT-HEX DC60-50148B 1 ●●●●
17 WD008 BELT-TRANSMISSION DC66-10139B 1 ●●●● ❍
18 WDD08 CUSHION-MOTOR DC61-00041A 1 ●●●●
19 WDD09 MOTOR-DRUM DC31-00002C 1 ●●●● ❍
20 WZ013 NUT-HEX DC60-50156A 1 ●●●●
21 WZ010 BAND RING DC65-60118F 1 ●●●●
22 WDD10 HOSE-FILTER TUB DC62-10304A 1 ●●●● ❍
23 WZ015 CLAMP-HOSE DC61-60497A 1 ●●●●
24 WDD11 PACKING-TRAP DC62-40184A 1 ●●●●
25 WD009 CAP-TRAP DC61-10676A 1 ●●●● ❍
26 WDD12 HEATER DC62-50123A 1 ●●● ❍
DC47-00001A 1 ●❍
27 WDD13 TUB-FRONT DC61-30346A 1 ●●●● ❍
28 WDD14 BRACKET-NUT DC61-40348B 5 ●●●●
29 WDD15 BRACKET-HEATER DC61-40344A 1 ●●●●
30 WDD16 SPACER-HEATER DC61-60496A 2 ●●●●
31 WDD17 VANE-CHECK DC62-20311A 1 ●●●●
32 WDD18 ASSY-DRUM DC97-00785A 1 ●❍
DC91-12281A 1 ●❍
DC97-00785B 1 ●● ❍
33 WDD19 PACKING-TUB DC62-40183A 1 ●●●●
34 WDD20 CLIP-TUB DC61-60499B 8 ●●●●
35 WDD21 ASSY-TUB BACK DC97-00214C 1 ●❍
DC97-00214B 1 ●● ❍
DC97-00214A 1 ●❍
36 WDD20 CLIP-TUB DC61-60520A 1 ●●●●
To Next Page
